凯斯零件查询(LBX332P) - BIG RECTANGULAR BALER ''PACKER CUTTER'' (3/03-12/08) (01.03A[01]) - POWER TAKE-OFF, REAR Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
719 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
84818971
|
[1] |
PTO
|
ZED
(2-24)
|
| 2. |
84819699
|
[1] |
PTO
|
ZED
(3-5)
|
| 3. |
84819706
|
[1] |
PTO SHAFT
|
ZED
(4, 5)
|
| 4. |
NSS
|
[1] |
NOT SOLD SEPARAT
|
CON
|
| 5. |
80750220
|
[2] |
LUBE NIPPLE
|
ZED
|
| 7. |
84819701
|
[1] |
PROTECTING COVER
|
ZED
(8-11)
|
| 8. |
84819707
|
[2] |
PROTECTION CAP
|
ZED
|
| 10. |
84819708
|
[2] |
PROTECTION CAP
|
ZED
|
| 11. |
80379650
|
[1] |
CHAIN
|
ZED
Superseded by part number: 87586692
|
| 12. |
84819700
|
[1] |
PTO
|
ZED
(6, 8, 10, 13-24)
|
| 13. |
84819709
|
[1] |
COVER
|
ZED
|
| 14. |
84819702
|
[1] |
PROTECTING COVER
|
ZED
(6, 8, 10, 15)
|
| 16. |
84819705
|
[1] |
PTO SHAFT
|
ZED
|
| 17. |
84819704
|
[1] |
YOKE
|
ZED
|
| 18. |
80412360
|
[1] |
ROLL PIN
|
ZED
Superseded by part number: 838-31090
|
| 19. |
84819703
|
[1] |
SPIDER
|
ZED
(20, 21, 25) Superseded by part number: 84355349
|
| 20. |
150024
|
[1] |
LUBE NIPPLE,45 Degree, M8 x 1
|
NH
|
| 22. |
84037057
|
[1] |
YOKE
|
ZED
(23, 24)
|
| 24. |
84037058
|
[1] |
LOCK PIN
|
ZED
Superseded by part number: 84031204
|
