凯斯零件查询(LBX332P) - BIG RECTANGULAR BALER ''PACKER CUTTER'' (3/03-12/08) (01.05A[01]) - POWER TAKE-OFF, REAR Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
674 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
84818969
|
[1] |
PTO
|
ZED
(2-22)
|
| 2. |
84819719
|
[1] |
PTO
|
ZED
(3-17)
|
| 3. |
84037057
|
[2] |
YOKE
|
ZED
(4, 5)
|
| 4. |
84037058
|
[2] |
LOCK PIN
|
ZED
Superseded by part number: 84031204
|
| 5. |
NSS
|
[2] |
NOT SOLD SEPARAT
|
CON
|
| 6. |
84819714
|
[2] |
SPIDER
|
ZED
(7-9) Superseded by part number: 84355349
|
| 8. |
80750236
|
[2] |
LUBE NIPPLE
|
ZED
Superseded by part number: 750236
|
| 10. |
84819704
|
[1] |
YOKE
|
ZED
|
| 11. |
80412360
|
[2] |
ROLL PIN
|
ZED
Superseded by part number: 838-31090
|
| 12. |
84819721
|
[1] |
PROPELLER SHAFT
|
ZED
|
| 13. |
84819702
|
[1] |
PROTECTING COVER
|
ZED
(14-17)
|
| 14. |
84819707
|
[2] |
PROTECTION CAP
|
ZED
|
| 17. |
84819708
|
[1] |
PROTECTION CAP
|
ZED
|
| 18. |
84819713
|
[1] |
PROTECTING COVER
|
ZED
(14, 15, 19)
|
| 19. |
84819718
|
[1] |
PROTECTION CAP
|
ZED
|
| 20. |
84819722
|
[1] |
PROPELLER SHAFT
|
ZED
|
| 21. |
84819717
|
[1] |
YOKE
|
ZED
|
| 22. |
84819720
|
[1] |
PTO
|
ZED
(3 to 9, 11, 14, 15, 19-21)
|
