纽荷兰零件查询(E70BSR) - COMPACT CRAWLER EXCAVATOR ASN YT06-18001 (01-083[01]) - HARNESS ASSEMBLY, UPPER New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
845 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YT13E00099F1 | [1] | Upp. | |
| 1. | YT13E01217P1 | [1] | WIRE HARNESS | KOB, Serial Range: YT06-18001-YT06-18441 Superseded by part number: YT13E01217P2 |
| 1. | YT13E01217P2 | [1] | WIRE HARNESS | KOB, Start Serial: YT06-18442 |
| 2. | YT13E01145P2 | [1] | ELECTRIC CABLE | KOB |
| 3. | YT13E01142P1 | [1] | ELECTRIC CABLE | KOB |
| 4. | YT13E01143P1 | [1] | ELECTRIC CABLE | KOB |
| 5. | YT13E01144P2 | [1] | ELECTRIC CABLE | KOB |
| 6. | LE13E01006P1 | [1] | HARNESS | KOBCable |
| 7. | EW02E01015D9 | [7] | CLIP,20mm ID, P Type | KOB |
| 8. | PY01P01043D3 | [70] | CABLE TIE,188mm L | KOB |
| 9. | YN13E01375P1 | [33] | CLIP,M8 x 8.20mm Shank | KOB |
| 10. | ZC46X46014 | [2] | CLIP | KOB |
| 11. | EW02E01015DF | [1] | CLIP | KOB |
| 12. | ZM73C08016 | [13] | BOLT,M8x16mm - Course Thread | KOBSems |
| 13. | ZM73C10020 | [1] | BOLT,M10x20mm - Course Thread | KOBSems |
