纽荷兰零件查询(E70BSR) - COMPACT CRAWLER EXCAVATOR ASN YT06-18001 (01-083[03]) - HARNESS ASSEMBLY, UPPER New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
179 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | YT13E01127P1 | [1] | BRACKET | KOB |
| 2. | EW02E01015D9 | [7] | CLIP,20mm ID, P Type | KOB |
| 3. | EW02E01015D4 | [1] | CLIP | KOB |
| 4. | EW02E01015DD | [2] | CLIP | KOB |
| 5. | PY01P01043DA | [4] | CABLE TIE,2.50mm W x 205mm L | KOB |
| 6. | PY01P01043D3 | [70] | CABLE TIE,188mm L | KOB |
| 7. | YN13E01375P1 | [33] | CLIP,M8 x 8.20mm Shank | KOB |
| 8. | ZS16C05012 | [2] | CAPTIVE WASHER SCREW | KOB |
| 9. | ZM73C08016 | [13] | BOLT,M8x16mm - Course Thread | KOBSems |
| 10. | ZM73C10020 | [12] | BOLT,M10x20mm - Course Thread | KOBSems |
| 11. | ZW26X05000 | [2] | LOCK WASHER | KOBLock |
| 12. | ZW16P05000 | [3] | WASHER | KOB |
| 13. | ZN18C05004 | [1] | NUT | KOB |
| 14. | EW02E01016D8 | [1] | CLIP | KOB |
