纽荷兰零件查询(E70SR) - MIDI CRAWLER EXCAVATOR ASN YT04-07175 (07-009) - VALVE ASSY, CONTROL (2-PIECE BOOM, OFFSET BOOM) New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
357 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YT30V00014F4 | [1] | CONTROL VALVE | KOBASSY |
| 1. | YT30V00001F4 | [1] | VALVE | KOBASSY, CONTROL, SEE FIG. 07-001 |
| 1-1. | YN01V00004S006 | [1] | O-RING | KOB |
| 1-2. | ZD12P02200 | [4] | O-RING | KOB |
| 2. | YT30V00011F1 | [1] | CONTROL VALVE | KOBASSY |
| 2-1. | YT30V00018F1 | [1] | CONTROL VALVE | KOBASSY, SEE FIG. 07-004-01 & 07-004-02 |
| 2-1A. | YT22V00004F1 | [1] | VALVE | KOBASSY, OVERLOAD RELIEF, SEE FIG. 07-008 |
| 2-2. | ZS23C12065 | [4] | SCREW,Hex Socket Head, M12 x 65mm | KOBCAP |
