| 1. |
84819492
|
[1] |
RESERVOIR, HYDRAULIC
|
ZED
(2, 3, 36, 37, 42), Serial Range: -C663 Superseded by part number: 84398983
|
| 1. |
87758394
|
[1] |
RESERVOIR, HYDRAULIC
|
ZED
, Start Serial: D664 Superseded by part number: 84398983
|
| 2. |
84078485
|
[1] |
PLUG
|
ZED
|
| 3. |
84819493
|
[1] |
FILLER CAP
|
ZED
|
| 4. |
84074610
|
[1] |
HYD CONNECTOR
|
ZED
(5)
|
| 5. |
84032746
|
[1] |
O-RING,2.1mm Thk x 15.4mm ID, 90 Duro
|
ZED
|
| 6. |
150014
|
[1] |
FERRULE
|
ZED
10 MM
|
| 7. |
86548975
|
[1] |
PIPE UNION NUT,M16 x 1.5
|
ZED
M10
|
| 8. |
371539
|
[1] |
HYD TUBE,2000 mm Length
|
ZED
D= 10 MM, L= 2 MM
|
| 9. |
84064606
|
[2] |
HYD CONNECTOR
|
ZED
|
| 10. |
84068686
|
[1] |
HYDRAULIC OIL FILTER
|
ZED
ASSEMBLY, (11)
|
| 11. |
84078520
|
[1] |
HYDRAULIC OIL FILTER
|
ZED
ELEMENT
|
| 12. |
84007700
|
[1] |
ELBOW
|
ZED
|
| 13. |
9813512
|
[1] |
HYD CONNECTOR
|
ZED
Superseded by part number: 89813512
|
| 14. |
84043514
|
[1] |
HYD CONNECTOR
|
ZED
|
| 15. |
335136
|
[1] |
FERRULE
|
ZED
8 MM
|
| 16. |
335135
|
[1] |
TUBE NUT,M14 x 1.5
|
ZED
8MM Tube O.D.
|
| 17. |
371540
|
[1] |
HYD TUBE,2000 mm Length
|
ZED
D= 8 MM, L= 2 M
|
| 18. |
87326530
|
[1] |
HYD TUBE,8 mm DIA x 100 mm L
|
ZED
(15, 16) D= 8 MM, L= 0.1 M
|
| 19. |
322358
|
[1] |
BELLEVILLE WASHER,M8 Bolt Size x 18mm OD x 1.4mm Thk
|
NH
|
| 20. |
84818476
|
[2] |
SUPPORT
|
ZED
|
| 21. |
86977790
|
[3] |
BOLT,Hex, M6 x 45mm, Cl 8.8
|
ZED
M6 x 45
|
| 22. |
140015
|
[1] |
WASHER,6.4mm ID x 14mm OD x 1.6mm Thk
|
NH
Superseded by part number: 9820463
|
| 23. |
412152
|
[1] |
NUT,M6 x 1, Cl 8.8
|
ZED
|
| 24. |
84460187
|
[1] |
HYDRAULIC VALVE
|
ZED
(50, 51)
|
| 25. |
84441294
|
[4] |
HYD CONNECTOR
|
ZED
|
| 26. |
379430
|
[1] |
3 WAY CONNECTION
|
ZED
|
| 27. |
84041508
|
[1] |
HYD CONNECTOR
|
ZED
|
| 28. |
84458460
|
[1] |
HOSE,8.00 mm ID x 650.00 mm
|
ZED
|
| 29. |
913888
|
[2] |
HOSE CLAMP
|
ZED
, Serial Range: -C663
|
| 29. |
574518
|
[2] |
HOSE CLAMP,6.3mm - 15.7mm, SAE # 4
|
NH
, Start Serial: D664 Superseded by part number: 86625022
|
| 30. |
84064667
|
[1] |
HYD CONNECTOR
|
ZED
|
| 31. |
84801502
|
[1] |
MEASURING INSTRUMENT
|
ZED
|
| 32. |
120104
|
[4] |
BOLT,Hex, M8 x 1.25 x 20mm, Cl 8.8
|
NH
|
| 34. |
89706690
|
[1] |
NUT,M8, Cl 8
|
ZED
Superseded by part number: 43362
|
| 35. |
412215
|
[2] |
BOLT,Hex, M8 x 1.25 x 100mm, Cl 8.8
|
NH
|
| 36. |
84819494
|
[1] |
HYDRAULIC OIL FILTER
|
ZED
|
| 37. |
84457448
|
[1] |
LEVEL GAUGE
|
ZED
|
| 38. |
9511936
|
[3] |
RIVET
|
ZED
|
| 39. |
87324041
|
[1] |
HYD TUBE
|
ZED
|
| 40. |
16043224
|
[2] |
BOLT,Hex, M8 x 16mm, Cl 8.8
|
NH
, Serial Range: -C663
|
| 40. |
120103
|
[2] |
BOLT,M8 x 1.25 x 16mm, Cl 8.8
|
NH
, Start Serial: D664 Superseded by part number: 16043224
|
| 41. |
84074545
|
[1] |
HYD CONNECTOR
|
ZED
|
| 42. |
84320893
|
[1] |
TUBE
|
ZED
, Serial Range: -C663
|
| 43. |
323597
|
[2] |
CABLE TIE,165mm OAL x 9mm Thk
|
NH
CABLE STRAP Superseded by part number: 14560287
|
| 44. |
43127
|
[2] |
BOLT,Hex, M8 x 1.25 x 25mm, Cl 8.8
|
NH
|
| 45. |
87324895
|
[1] |
HYD TUBE
|
ZED
(15, 16) D= 8 MM, L= 907 MM
|
| 46. |
87325287
|
[1] |
HYD TUBE
|
ZED
(15, 16) D= 8 MM, L= 685 MM
|
| 47. |
87324694
|
[1] |
HYD TUBE
|
ZED
(15, 16) D= 8 MM, L= 1394 MM
|
| 48. |
87324884
|
[1] |
HYD TUBE
|
ZED
(15, 16) D= 8 MM, L= 1597 MM
|
| 49. |
87325291
|
[1] |
HYD TUBE
|
ZED
(15, 16) D= 8 MM, L= 663 MM
|
| 50. |
87357750
|
[1] |
MAGNET
|
ZED
|
| 50. |
87357749
|
[1] |
HYDRAULIC VALVE
|
ZED
|
| 51. |
87357756
|
[1] |
HYDRAULIC VALVE
|
ZED
Superseded by part number: 247697A2
|
| 52. |
140093
|
[1] |
WASHER
|
ZED
, Start Serial: D588 Superseded by part number: 80140093
|
| 53. |
9513082
|
[1] |
FITTING
|
PA
, Start Serial: D664
|
| 55. |
100065
|
[1] |
JAM NUT,M14 x 1.5, Cl 8
|
ZED
, Start Serial: D664 Superseded by part number: 80100065
|
| 56. |
84025707
|
[1] |
HYD CONNECTOR
|
PLO
, Start Serial: D664
|
