纽荷兰零件查询(E70SR) - MIDI CRAWLER EXCAVATOR ASN YT04-07175 (08-005) - OIL PAN AND LEVEL GAUGE New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
664 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1F. | VI8972539851 | [1] | ENGINE OIL PAN | KOBPAN ASM; OIL |
| 2B. | VI8970479310 | [1] | GAUGE | KOBGAUGE; OIL LEVEL Superseded by part number: VI8980553230 |
| 3. | VI1096230570 | [1] | O-RING | KOBGASKET; DRAIN PLUG, ID=24.4 Superseded by part number: 87380148 |
| 4. | VI9096620120 | [1] | DRAIN PLUG | KOBPLUG; DRAIN, OIL M20 |
| 16. | VI8970801940 | [1] | SUMP | KOBGASKET; OIL PAN TO C/BL |
| 23. | VI8941339732 | [10] | BOLT | KOBBOLT; OIL PAN M8 X 18.9 |
| 24. | VI5094400100 | [12] | NUT | KOBNUT; OIL PAN Superseded by part number: VI0911802080 |
| 290A. | VI8972300700 | [1] | STIFFENER | KOBSTIFFNER; OIL PAN |
| 290B. | VI8972300690 | [1] | STIFFENER | KOBSTIFFNER; OIL PAN |
| 291A. | VI0286810400 | [4] | BOLT | KOBBOLT; STIFFNER OIL PAN, M10 X 40, FLANGE |
| 291B. | VI0286812300 | [2] | BOLT | KOBBOLT; STIFFNER OIL PAN, M12 X 30, FLANGE |
