纽荷兰零件查询(E70SR) - MIDI CRAWLER EXCAVATOR ASN YT04-07175 (08-006) - CAMSHAFT AND VALVE New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
682 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | VI8972876570 | [1] | CAMSHAFT | KOBCAMSHAFT |
| 4. | VI8941332751 | [4] | VALVE | KOBVALVE; INL Superseded by part number: VI8941332752 |
| 5. | VI8970659700 | [4] | VALVE | KOBVALVE; EXH Superseded by part number: VI8971187671 |
| 9. | VI8943243361 | [1] | GEAR | KOBGEAR; CM/SHF |
| 10. | VI8941104801 | [1] | PLATE | KOBPLATE; THRUST |
| 11. | VI0500408160 | [2] | BOLT | KOBBOLT; THRUST PLATE TO C/BL M8 X 16 W/LK WASHER |
| 14. | VI9080007180 | [1] | KEY | KOBKEY; CM/SHF |
| 28. | VI5090000690 | [1] | BOLT | KOBBOLT; CAM PULLEY M12 X 47 |
| 45. | VI5125190021 | [1] | WASHER | KOBWASHER; GEAR CAM |
| 53. | VI8941523460 | [1] | ROCKER ARM | KOBSHAFT; ROCKER ARM Superseded by part number: VI8970361970 |
| 55. | VI9126260050 | [2] | PLUG | KOBPLUG; ROCKER SHAFT END |
| 56. | VI9091800190 | [2] | SNAP RING | KOBRING; SNAP, ROCKER ARM |
| 65. | VI5125650040 | [16] | COLLAR | KOBCOLLAR; SPLIT |
| 69. | VI8942525361 | [8] | SPRING | KOBSPRING; VLV, OUTER |
| 71A. | VI5125630010 | [8] | SEAT | KOBSEAT; SPR OD=34 |
| 71B. | VI8941337312 | [8] | SEAT | KOBSEAT; SPR OD=32.8 |
| 78. | VI8941523440 | [8] | ROCKER ARM | KOBARM; ROCKER |
| 81. | VI8941522831 | [8] | SCREW | KOBSCREW; ADJ, ROCKER ARM, M8 X 30 |
| 83. | VI9091115080 | [8] | NUT | KOBNUT; ADJ SCREW, LK Superseded by part number: VI0911115080 |
| 84. | VI8941523451 | [4] | BRACKET | KOBBRACKET; ROCKER SHAFT, INTER |
| 85. | VI8944333020 | [1] | BOLT | KOBBOLT; BRKT M10 X 60 |
| 87. | VI8944333040 | [3] | BOLT | KOBBOLT; ROCKER SHAFT M8 X 15 & M10 X 60 L=82 |
| 88. | VI8970716730 | [8] | PUSH ROD | KOBROD; PUSH |
| 89. | VI8944383051 | [8] | TAPPET | KOBTAPPET; VALVE |
| 94. | VI9091640100 | [4] | WASHER | KOBWASHER; PL, BRKT Superseded by part number: VI9091645100 |
| 104. | VI8941097061 | [1] | SHAFT | KOBBOLT; SHAFT IDLE |
| 107. | VI8979200070 | [1] | SHAFT | KOBSHAFT; IDLE GEAR |
| 109. | VI8941099131 | [1] | SHAFT | KOBSHAFT; IDLE GEAR |
| 111. | VI8941419371 | [1] | COLLAR | KOBCOLLAR; THRUST, IDLE GEAR |
| 112. | VI8943282170 | [1] | GEAR | KOBGEAR; IDLER Z=43 |
| 113. | VI8971473340 | [1] | GEAR | KOBGEAR; IDLE Z=52 |
| 204. | VI5090000841 | [2] | BOLT | KOBBOLT; IDLE GEAR SHAFT, M8 X 55 W/LK WASHER Superseded by part number: VI8941500451 |
| 226. | VI8944333030 | [3] | SPRING | KOBSPRING; CMPR, ROCKER ARM |
| 305. | VI8941102710 | [1] | BEARING | KOBBEARING; IDLER GEAR |
