| 1. |
89837395
|
[1] |
HANDLE
|
ZED
Superseded by part number: 9837395
|
| 2. |
84807440
|
[2] |
SUPPORT
|
ZED
, Serial Range: -C535
|
| 3. |
84807437
|
[1] |
SHIELD
|
ZED
|
| 3. |
84807452
|
[1] |
SHIELD
|
ZED
|
| 4. |
84807456
|
[1] |
SUPPORT
|
ZED
, Serial Range: -C535
|
| 4. |
87329900
|
[1] |
SUPPORT
|
ZED
, Start Serial: D536
|
| 4. |
84807454
|
[1] |
SUPPORT
|
ZED
, Serial Range: -C535
|
| 4. |
87329897
|
[1] |
SUPPORT
|
ZED
, Start Serial: D536
|
| 5. |
80336455
|
[4] |
PLUG
|
ZED
Superseded by part number: 336455
|
| 6. |
84017837
|
[1] |
BRACKET
|
ZED
|
| 7. |
84000555
|
[2] |
INSULATOR,Bumper
|
ZED
|
| 8. |
84015292
|
[1] |
LATCH
|
ZED
|
| 9. |
80401266
|
[1] |
STRIP-GASKET
|
ZED
L= 0.3 M Superseded by part number: 401266
|
| 10. |
84607903
|
[1] |
GUARD
|
ZED
|
| 10. |
84819358
|
[1] |
GUARD
|
ZED
|
| 11. |
84100274
|
[2] |
HINGE
|
ZED
|
| 12. |
84607901
|
[1] |
SHIELD
|
ZED
, Serial Range: -C535
|
| 12. |
84607900
|
[1] |
PLATE
|
ZED
, Serial Range: -C535
|
| 12. |
87392010
|
[1] |
PLATE
|
ZED
, Start Serial: D536
|
| 13. |
84607897
|
[1] |
PLATE
|
ZED
, Serial Range: -C535
|
| 14. |
84607896
|
[1] |
PLATE
|
ZED
, Serial Range: -C535
|
| 15. |
84078201
|
[2] |
BRACKET
|
ZED
, Serial Range: -C535
|
| 16. |
89837397
|
[2] |
GAS STRUT
|
ZED
Superseded by part number: 9837397
|
| 17. |
84607899
|
[1] |
SHIELD
|
ZED
, Serial Range: -C535
|
| 17. |
84607898
|
[1] |
PLATE
|
ZED
, Serial Range: -C535
|
| 17. |
87392016
|
[1] |
PLATE
|
ZED
, Start Serial: D536
|
| 18. |
80043442
|
[2] |
NUT,M8 x 1.25, Cl 8
|
ZED
, Serial Range: -C535 Superseded by part number: 82034883
|
| 18. |
412250
|
[2] |
NUT,M8 x 1.25, Cl 8
|
WIN
, Start Serial: D536 Superseded by part number: 86528579
|
| 19. |
84100271
|
[2] |
HINGE
|
ZED
|
| 20. |
80140045
|
[4] |
WASHER
|
ZED
Belleville, M10 Superseded by part number: 140045
|
| 21. |
89839580
|
[2] |
SCREW,Hex Soc Hd, M8 x 70, 8.8
|
ZED
|
| 22. |
86512439
|
[1] |
CARRIAGE BOLT,M6 x 16mm, Cl 8.8
|
NH
|
| 23. |
80322357
|
[1] |
LOCK WASHER,Belleville, M6
|
ZED
Superseded by part number: 322357
|
| 24. |
15896221
|
[1] |
NUT,Hex, M6, 5.20mm High, Cl 10
|
ZED
Superseded by part number: 86500688
|
| 25. |
120104
|
[1] |
BOLT,Hex, M8 x 1.25 x 20mm, Cl 8.8
|
NH
|
| 26. |
80140016
|
[4] |
WASHER
|
ZED
8 MM Superseded by part number: 86624184
|
| 27. |
80322358
|
[1] |
LOCK WASHER
|
ZED
8 MM Superseded by part number: 322358
|
| 28. |
86508568
|
[6] |
BOLT,Hex, M6 x 1 x 16mm, Cl 8.8
|
NH
|
| 29. |
89706690
|
[1] |
NUT,M8, Cl 8
|
ZED
Superseded by part number: 43362
|
| 30. |
86507486
|
[22] |
CARRIAGE BOLT,M8 x 1.25 x 20mm, Cl 8.8
|
NH
|
| 31. |
100016
|
[2] |
NUT,M10 x 1.5, Cl 8
|
NH
|
| 32. |
89837364
|
[4] |
BALL JOINT
|
ZED
Superseded by part number: 9837417
|
| 33. |
84100868
|
[2] |
BRACKET
|
ZED
, Serial Range: -C435
|
| 34. |
84807438
|
[1] |
SHEET
|
ZED
LH, Serial Range: -C535
|
| 34. |
87335648
|
[1] |
PLATE
|
ZED
LH, Start Serial: D536
|
| 35. |
84807439
|
[1] |
PLATE
|
ZED
RH, Serial Range: -C535
|
| 35. |
87335651
|
[1] |
PLATE
|
ZED
RH, Start Serial: D536
|
| 36. |
80120041
|
[2] |
CARRIAGE BOLT
|
ZED
M10 x 20 Superseded by part number: 120041
|
| 37. |
412649
|
[11] |
BELLEVILLE WASHER,M6 Bolt Size x 18mm OD x 1.4mm Thk
|
ZED
, Start Serial: D536
|
| 38. |
100097
|
[2] |
JAM NUT,Thin, M8 x 1.25, Cl 04
|
GI
, Start Serial: D536 Superseded by part number: 103889
|
| 39. |
87364218
|
[2] |
DECAL
|
ZED
, Start Serial: D536
|
