| 1. |
84607889
|
[1] |
SHIELD
|
ZED
|
| 2. |
89837901
|
[1] |
ROD
|
ZED
Superseded by part number: 9837901
|
| 3. |
84607888
|
[1] |
SHIELD
|
ZED
|
| 4. |
86511478
|
[1] |
BOLT,Hex Serr, M8 x 1.25 x 16mm
|
ZED
|
| 5. |
84607744
|
[1] |
SHIELD
|
ZED
|
| 6. |
86505868
|
[1] |
SERRATED NUT,Hex, M8 x 1.25, Cl 8
|
ZED
|
| 7. |
80437424
|
[2] |
COTTER PIN
|
ZED
Superseded by part number: 437424
|
| 8. |
84607885
|
[1] |
SHIELD
|
ZED
Has Curved Pipe at each end, similar to Ref 9
|
| 8. |
84607886
|
[1] |
WINDGUARD
|
ZED
Has Curved Pipe at each end, similar to Ref 9
|
| 9. |
84078429
|
[1] |
CENTRAL RAIL
|
ZED
|
| 9. |
84078427
|
[1] |
CENTRAL RAIL
|
ZED
|
| 10. |
80300662
|
[2] |
BOLT
|
ZED
M12 x 80 Superseded by part number: 300662
|
| 11. |
84818993
|
[1] |
CHAIN,1464mm L
|
ZED
|
| 12. |
120103
|
[2] |
BOLT,M8 x 1.25 x 16mm, Cl 8.8
|
NH
Superseded by part number: 16043224
|
| 13. |
80378243
|
[2] |
WASHER
|
ZED
8 MM Superseded by part number: 378243
|
| 14. |
84607740
|
[3] |
REEL TINE
|
ZED
, Serial Range: -C439 Superseded by part number: 84801138
|
| 14. |
84801138
|
[3] |
REEL TINE
|
ZED
, Start Serial: D440
|
| 15. |
80395087
|
[2] |
INSULATOR BLOCK
|
ZED
Superseded by part number: 89513995
|
| 16. |
84056308
|
[7] |
PLATE
|
ZED
|
| 17. |
80322358
|
[1] |
LOCK WASHER
|
ZED
8 MM Superseded by part number: 322358
|
| 18. |
80378245
|
[1] |
WASHER
|
ZED
12 MM Superseded by part number: 378245
|
| 19. |
80100038
|
[1] |
NUT
|
ZED
M12 Superseded by part number: 100038
|
| 20. |
86507486
|
[1] |
CARRIAGE BOLT,M8 x 1.25 x 20mm, Cl 8.8
|
NH
|
| 21. |
84607739
|
[4] |
REEL TINE
|
ZED
, Serial Range: -C439 Superseded by part number: 84801139
|
| 21. |
84801139
|
[4] |
REEL TINE
|
ZED
, Start Serial: D440
|
| 22. |
84607742
|
[1] |
COVER PLATE
|
ZED
|
| 23. |
80140045
|
[1] |
WASHER
|
ZED
Belleville, M10 Superseded by part number: 140045
|
| 24. |
86512446
|
[1] |
CARRIAGE BOLT,M10 x 1.5 x 30mm, Cl 8.8
|
NH
|
| 25. |
84607741
|
[1] |
COVER PLATE
|
ZED
|
| 26. |
89837915
|
[1] |
ROD
|
ZED
Superseded by part number: 9837915
|
| 27. |
84607890
|
[1] |
SHIELD
|
ZED
|
| 28. |
84607814
|
[1] |
SHIELD
|
ZED
|
| 29. |
84607734
|
[4] |
HINGE
|
ZED
|
| 30. |
84607745
|
[1] |
SHIELD
|
ZED
|
| 31. |
89706690
|
[1] |
NUT,M8, Cl 8
|
ZED
Superseded by part number: 43362
|
| 32. |
100016
|
[4] |
NUT,M10 x 1.5, Cl 8
|
NH
|
| 33. |
84429041
|
[1] |
LOCKING RING
|
ZED
|
| 34. |
80043140
|
[1] |
BOLT,M10 x 1.5 x 30mm, Cl 8.8
|
ZED
Superseded by part number: 43140
|
| 35. |
84449012
|
[1] |
SUPPORT
|
ZED
, Serial Range: -C455 Superseded by part number: 87323341
|
| 35. |
87323341
|
[1] |
SUPPORT
|
ZED
, Start Serial: D456
|
| 35. |
84449010
|
[1] |
SUPPORT
|
ZED
, Serial Range: -C455 Superseded by part number: 87323476
|
| 35. |
87323476
|
[1] |
SUPPORT
|
ZED
, Start Serial: D456
|
| 36. |
80120044
|
[2] |
BOLT
|
ZED
M12 x 30 Superseded by part number: 120044
|
| 37. |
80140046
|
[2] |
WASHER
|
ZED
12 MM Superseded by part number: 140046
|
| 38. |
89706685
|
[2] |
NUT
|
ZED
M12 Superseded by part number: 9706685
|
| 39. |
338263
|
[2] |
CARRIAGE BOLT,Sht Sq Nk, M12 x 1.75 x 70mm, Cl 8.8
|
ZED
|
| 40. |
378244
|
[1] |
WASHER,10.5mm ID x 24mm OD x 2mm Thk
|
NH
|
| 41. |
100037
|
[1] |
LOCK NUT,M10 x 1.5, Cl 8
|
NH
|
| 42. |
291186
|
[1] |
PROTECTION STRIP,9.9mm W
|
NH
L=0.10 M Superseded by part number: 47560081, 47560080
|
