凯斯零件查询(LBX332P) - BIG RECTANGULAR BALER ''PACKER CUTTER'' (3/03-12/08) (08.008A[01]) - TWINE BOX, LH Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
469 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
84444396
|
[1] |
SUPPORT
|
ZED
|
| 2. |
84819698
|
[1] |
SUPPORT
|
ZED
|
| 3. |
84819378
|
[1] |
SUPPORT
|
ZED
|
| 4. |
89837572
|
[1] |
CLAMP
|
ZED
, Serial Range: -C479 Superseded by part number: 87332566
|
| 4. |
87332566
|
[1] |
FIXING PLATE
|
ZED
, Start Serial: D480
|
| 5. |
84444412
|
[1] |
GUIDE BUSHING
|
ZED
, Serial Range: -C479 Superseded by part number: 87331610
|
| 5. |
87331610
|
[1] |
GUIDE
|
ZED
, Start Serial: D480
|
| 6. |
84444540
|
[1] |
WASHER,35mm ID x 45mm OD x 2mm Thk
|
ZED
35 MM
|
| 7. |
80370004
|
[1] |
CIRCLIP
|
ZED
Superseded by part number: 11068376
|
| 8. |
86507486
|
[1] |
CARRIAGE BOLT,M8 x 1.25 x 20mm, Cl 8.8
|
NH
|
| 9. |
86511323
|
[1] |
WASHER,10.5mm ID x 20mm OD x 2mm Thk
|
NH
Superseded by part number: 14496621
|
| 10. |
80322358
|
[1] |
LOCK WASHER
|
ZED
8 MM Superseded by part number: 322358
|
| 11. |
89706690
|
[1] |
NUT,M8, Cl 8
|
ZED
Superseded by part number: 43362
|
| 12. |
80338949
|
[1] |
CARRIAGE BOLT
|
ZED
M10 x 25 Superseded by part number: 338949
|
| 12. |
43140
|
[1] |
BOLT,Hex, M10 x 1.5 x 30mm, Cl 8.8
|
NH
|
| 13. |
80140045
|
[15] |
WASHER
|
ZED
10 MM Superseded by part number: 140045
|
| 14. |
100016
|
[15] |
NUT,M10 x 1.5, Cl 8
|
NH
|
| 15. |
80120041
|
[1] |
CARRIAGE BOLT
|
ZED
M10 x 20 Superseded by part number: 120041
|
| 15. |
120228
|
[1] |
HEX SOC SCREW,M8 x 20mm, Cl 8.8, Full Thd
|
ZED
|
| 16. |
84819384
|
[1] |
COVER
|
ZED
|
| 17. |
84819382
|
[1] |
SUPPORT
|
ZED
|
| 17. |
84819380
|
[1] |
SUPPORT
|
ZED
|
| 18. |
120104
|
[4] |
BOLT,Hex, M8 x 1.25 x 20mm, Cl 8.8
|
NH
|
| 19. |
378243
|
[4] |
WASHER,8.4mm ID x 21mm OD x 1.6mm Thk
|
NH
Superseded by part number: 63707, 63707, 86625263
|
