神钢零件查询(K935) - EXCAVATOR SUPPLEMENT ASN LU00154 (1/76-12/03) (05-001) - AIR-LINES UPP P/N 24100X1156F1,F3 Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
781 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24100X1156F1 | [1] | AIR-LINES UPP | |
| . . | 24100X1156F3 | [1] | AIR-LINES UPP | |
| 1. | R38N0012 | [1] | RESERVOIR | KOB |
| 2. | R38T0014 | [3] | VALVE | KOB |
| 3. | 2446U156F1 | [1] | VALVE PRESSURE RELIE | KOB |
| 3-21. | 2446U133S21 | [1] | AIR FILTER | KOB |
| 3-22. | 2446U133S22 | [1] | O-RING | KOB |
| 3-30. | 2446U156S30 | [1] | BOWL | KOB |
| 4. | R38N0014 | [1] | KIT DIA, CRAWLER EXC | KOB |
| 5. | B90P0027F2 | [1] | VALVE ASSY | |
| 5-1. | R38N0008 | [1] | VALVE | KOB |
| 5-7. | 2406T2050 | [1] | LEVER | |
| 6. | R38T0001D4 | [1] | VALVE PRESSURE RELIE | KOB |
| 7. | 2447U2 | [1] | HORN | KOB Superseded by part number: 2447U46 |
| 8. | R44P0046D3 | [2] | ELBOW | KOB |
| 9. | R27T0016 | [1] | HINGE | KOB |
| 10. | B20T0041 | [2] | U-BOLT | KOB |
| 11. | 2418P3715 | [2] | TUBE | TUBE |
| 12. | 2444Z1624D3 | [1] | HOSE | HOSE |
| 13. | 2444T1169 | [2] | HYD CONNECTOR | KOB |
| 14. | 2444T1170 | [2] | HYD CONNECTOR | KOB |
| 15. | R44P0043D2 | [4] | HYD CONNECTOR | KOB |
| 16. | R38T0002 | [1] | COCK, DRAIN | COCK, DRAIN |
| 17. | 2444Z1695D4 | [1] | HYD CONNECTOR | KOB |
| 18. | ZC15X01500 | [4] | CLIP | KOB |
| 19. | R16P0036D1 | [6] | CLAMP | KOB Superseded by part number: ZC46X12011 |
| 20. | R16T0063D3 | [1] | GROMMET | KOB |
| 21. | R16T0063D4 | [1] | GROMMET | KOB |
| 22. | R16T0063D5 | [1] | GROMMET | |
| 23. | 2418T7933 | [2] | TUBE | TUBE |
| 24. | ZX15K06350 | [1] | TUBE, NYLON | TUBE, NYLON |
| 25. | ZX15K06150 | [2] | TUBE | KOB |
| 26. | ZX15K06400 | [1] | TUBE | KOB |
| 27. | ZX15K06300 | [1] | TUBE, NYLOM, N2 | TUBE, NYLOM, N2 |
| 26. | ZX15K06250 | [1] | TUBE, N2 | TUBE, N2 |
| 29. | ZX15K06100 | [1] | TUBE, NYLON | TUBE, NYLON |
| 30. | ZX15K06020 | [2] | TUBE, NYLON | TUBE, NYLON |
| 31. | ZX15K04350 | [1] | TUBE, NYLON | TUBE, NYLON |
| 32. | ZH21K04004 | [6] | HYD CONNECTOR | KOB |
| 32. | ZX15K04200 | [2] | TUBE | KOB |
| 33. | ZX15K04500 | [1] | TUBE, NYLON, N2 | TUBE, NYLON, N2 |
| 34. | ZX15K04300 | [1] | TUBE | KOB |
| 36. | ZG22E04000 | [4] | HYD CONNECTOR | KOB |
| 37. | ZH21K04004 | [4] | HYD CONNECTOR | KOB |
| 38. | ZG21E06004 | [2] | CONNECTOR | CONNECTOR |
| 39. | ZH21K06004 | [3] | CONNECTOR | CONNECTOR |
| 40. | ZH31K04004 | [5] | ELBOW | KOB |
| 41. | ZH31K06004 | [5] | ELBOW | KOB |
| 42. | ZH31K06006 | [1] | ELBOW | ELBOW |
| 43. | ZG21U04000 | [4] | SOCKET | KOB |
| 44. | ZG21U06000 | [2] | HYD CONNECTOR | KOB |
| 45. | ZG51U04000 | [2] | TEE | KOB |
| 46. | ZH51K04004 | [1] | TEE | |
| 47. | 2444Z1944D1 | [2] | TEE | |
| 48. | R44T0102D1 | [1] | CROSS | CROSS |
| 51. | ZS11C10016 | [2] | CAPSCREW M10x1.50x16mm | CAPSCREW M10x1.50x16mm |
| 52. | ZS11C08012 | [7] | SCREW,Hex, M8 x 12mm, Cl 4.8 | KOBM08x1.25x12mm Superseded by part number: ZS18C08012 |
| 53. | ZS11C06025 | [2] | CAPSCREW M06x1.0x25mm | CAPSCREW M06x1.0x25mm |
| 54. | ZS11C06012 | [2] | SCREW,Hex, M6 x 12mm, Cl 4.8 | KOBM06x1.0x12mm Superseded by part number: ZS18C06012 |
| 55. | ZW22X10000 | [4] | LOCK WASHER | KOBID 10 x OD 18.4 x Th 2.5mm Superseded by part number: ZW26X10000 |
| 56. | ZW22X08000 | [13] | LOCK WASHER | KOBID 08 x OD 15.4 x Th 2.0mm Superseded by part number: 83990583 |
| 57. | ZW22X06000 | [4] | LOCK WASHER ID 06 x OD 12.2 x Th 1.5mm | LOCK WASHER ID 06 x OD 12.2 x Th 1.5mm |
| 58. | ZW11X10000 | [2] | WASHER | KOBID 10 x OD 21 x Th 2.0mm Superseded by part number: ZW16X10000 |
| 59. | ZW11X08000 | [2] | WASHER | KOBID 09 x OD 17 x Th 1.6mm Superseded by part number: ZW16X08000 |
| 60. | ZN11C08007 | [14] | NUT | KOBM08x1.25mm Superseded by part number: ZN16C08007 |
| 61. | ZN11C06005 | [4] | NUT | KOBNUT M06x1.0mm Superseded by part number: ZN18C06005 |
| 62. | ZE72T04000 | [1] | PLUG | KOB |
| 63. | ZG21U06004 | [2] | HYD CONNECTOR | KOB |
| 65. | ZH51K06004 | [1] | TEE | |
| 66. | ZH51K06000 | [1] | TEE | KOB |
| 73. | ZX15K04050 | [1] | TUBE, NYLON | |
| 74. | 2418T19255 | [2] | TUBE | |
| 75. | ZH31K04002 | [2] | ELBOW | KOB |
| 35. | VAMH032117 | [2] | HOSE AIR (MITSUBISHI PARTS) | HOSE AIR (MITSUBISHI PARTS) |
| 49. | VAMH035004 | [3] | GASKET (MITSUBISHI PARTS) | GASKET (MITSUBISHI PARTS) |
| 50. | VAMH035107 | [4] | GASKET | KOB(MITSUBISHI PARTS) Superseded by part number: VAMH035195 |
