神钢零件查询(K935) - EXCAVATOR SUPPLEMENT ASN LU00154 (1/76-12/03) (09-001) - WINTERIZATION UNIT-FOR ALASKA P/N 24100T246F1 Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
152 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24100T246F1 | [1] | WINTERIZATION UNIT (FOR ALASKA) | |
| 1. | 24100P465F1 | [1] | BATTERY ASSY | |
| 1-1. | 84Z52 | [2] | BATTERY | |
| 1-2. | ZW22X10000 | [2] | LOCK WASHER | KOBID 10 x OD 18.4 x Th 2.5mm Superseded by part number: ZW26X10000 |
| 1-3. | R20T0084D11 | [1] | CAPSCREW | |
| 1-4. | B16T0039 | [1] | SUPPORT | |
| 1-5. | B16T0040 | [1] | PLATE | |
| 1-6. | B16T0041 | [1] | PLATE | |
| 1-7. | R20T0084D10 | [1] | CAPSCREW | KOBSCREW M10x1.50x250mm |
| 2. | 2430U14408F1 | [1] | CABLE ASSY, CONTROL (L.4000) | |
| 2-4. | R06T0042D1 | [1] | END | KOB |
| 2-5. | B19T0175 | [1] | PIN | KOB |
| 2-6. | ZP15K01210 | [1] | LOCK PIN | KOB |
| 3. | 2430U144D9F1 | [1] | CABLE | KOBASSY |
| 3-4. | R06T0042D1 | [1] | END | KOB |
| 3-5. | B19T0175 | [1] | PIN | KOB |
| 3-6. | ZP15K01210 | [1] | LOCK PIN | KOB |
