| 1. |
80370006
|
[1] |
SNAP RING
|
ZED
Superseded by part number: 370006
|
| 2. |
84078690
|
[1] |
ADJUSTING PLATE
|
ZED
50 x 62 MM
|
| 3. |
80539450
|
[1] |
SHIM
|
ZED
Superseded by part number: 539450
|
| 4. |
84320401
|
[1] |
SUPPORT
|
ZED
|
| 5. |
84074230
|
[1] |
BUSHING,60mm ID x 65mm OD x 60mm L
|
ZED
|
| 6. |
84078578
|
[1] |
SPROCKET
|
ZED
|
| 7. |
80065319
|
[12] |
WASHER
|
PLO
12 MM Superseded by part number: 65319
|
| 8. |
89706693
|
[12] |
SCREW,M12 x 60mm
|
ZED
M12 x 60 Superseded by part number: 9706693
|
| 9. |
84074232
|
[1] |
SEAL,90mm ID x 110mm OD x 8mm Thk
|
ZED
|
| 10. |
80301652
|
[1] |
SNAP RING
|
ZED
Superseded by part number: 301652
|
| 11. |
80370013
|
[1] |
SNAP RING
|
ZED
Superseded by part number: 370013
|
| 12. |
84074234
|
[1] |
BEARING, ROLLER, CYL,60mm ID x 110mm OD x 28mm W
|
ZED
Superseded by part number: 428162
|
| 13. |
80552118
|
[1] |
SEAL
|
ZED
|
| 14. |
84074231
|
[1] |
ADJUSTING PLATE
|
ZED
|
| 15. |
84078076
|
[1] |
BEARING HOUSING,75 mm ID x 130 mm OD x 64 mm
|
ZED
|
| 16. |
80300389
|
[3] |
BOLT,M12 x 35mm
|
ZED
M12 x 35 Superseded by part number: 628-12035
|
| 17. |
80140046
|
[8] |
WASHER
|
ZED
12 MM Superseded by part number: 140046
|
| 18. |
84078663
|
[1] |
SHAFT
|
ZED
Superseded by part number: 48030939
|
| 19. |
84078614
|
[1] |
HYD CONNECTOR
|
ZED
|
| 20. |
84017119
|
[1] |
SET SCREW,Hex, M8 x 16mm, Cl 8.8
|
ZED
|
| 21. |
80322358
|
[1] |
LOCK WASHER
|
ZED
8 MM Superseded by part number: 322358
|
| 22. |
321204
|
[1] |
LUBE NIPPLE,M6 x 1.0 x 16mm OAL
|
ZED
|
| 23. |
100020
|
[2] |
NUT,M16 x 2.0, Cl 8
|
NH
|
| 24. |
80451743
|
[3] |
WASHER
|
ZED
Superseded by part number: 574245
|
| 25. |
80210049
|
[2] |
BALL BEARING
|
ZED
Superseded by part number: 210049
|
| 26. |
84039374
|
[1] |
WASHER
|
ZED
|
| 27. |
84039375
|
[1] |
DRIVEN SPROCKET
|
ZED
|
| 28. |
84039373
|
[1] |
BUSHING
|
ZED
|
| 29. |
80321246
|
[1] |
BOLT,M16 x 2 x 120mm, Cl 8.8
|
ZED
Superseded by part number: 321246
|
| 30. |
84056457
|
[1] |
IDLER LEVER
|
ZED
|
| 31. |
84320124
|
[1] |
CHAIN,Roller, 86 Links x 31.75mm = 2730.5mm, #100
|
ZED
(49)
|
| 32. |
89839353
|
[1] |
SPACER
|
ZED
Superseded by part number: 9839353
|
| 33. |
80300637
|
[1] |
SNAP RING
|
ZED
Superseded by part number: 300637
|
| 34. |
84320512
|
[1] |
DRIVEN SPROCKET
|
ZED
Z= 28 Superseded by part number: 47972548
|
| 35. |
84056456
|
[1] |
SUPPORT
|
ZED
|
| 36. |
89706685
|
[5] |
NUT
|
ZED
M12 Superseded by part number: 9706685
|
| 37. |
84041797
|
[1] |
THREADED ROD
|
ZED
M20 x 360
|
| 38. |
84056463
|
[1] |
HINGE
|
ZED
|
| 39. |
80378243
|
[1] |
WASHER
|
ZED
8 MM Superseded by part number: 378243
|
| 40. |
84012754
|
[1] |
O-RING,5mm Thk x 25mm ID, 70 Duro
|
ZED
|
| 41. |
80442203
|
[1] |
WASHER
|
ZED
Superseded by part number: 442203
|
| 42. |
84074866
|
[1] |
SHAFT
|
ZED
|
| 43. |
86729275
|
[2] |
LOCK WASHER,5/8 0.634 CST ZND
|
BHB
|
| 44. |
80043168
|
[2] |
BOLT
|
ZED
M16 x 40 Superseded by part number: 43168
|
| 45. |
84042491
|
[2] |
GUIDE
|
ZED
|
| 46. |
80120073
|
[4] |
SCREW,M10 x 80mm
|
ZED
M10 x 80 Superseded by part number: 129796A1
|
| 47. |
80140045
|
[8] |
WASHER
|
ZED
Belleville, M10 Superseded by part number: 140045
|
| 48. |
80100037
|
[4] |
NUT,M10 x 1.5, Class 8
|
ZED
Superseded by part number: 100037
|
| 49. |
84320517
|
[1] |
CONNECTING LINK
|
ZED
|
| 50. |
84004940
|
[1] |
SPHERICAL BEARING,20mm ID x 35mm OD x 16mm W
|
ZED
|
| 51. |
80370024
|
[1] |
CIRCLIP
|
ZED
Superseded by part number: 370024
|
| 52. |
84037293
|
[1] |
BUSHING,26mm ID x 40mm OD x 10mm L
|
ZED
|
| 53. |
84041795
|
[1] |
WASHER,26mm ID x 82mm OD x 10mm Thk
|
ZED
|
| 54. |
84011609
|
[1] |
INSULATOR BLOCK
|
ZED
|
| 55. |
84041794
|
[1] |
SUPPORT
|
ZED
|
| 56. |
9672396
|
[1] |
NUT
|
WIN
M20
|
| 57. |
89706694
|
[1] |
NUT,M20, Cl 8
|
ZED
Superseded by part number: 9706694
|
| 59. |
80370008
|
[1] |
SNAP RING,M50, Ext
|
ZED
Superseded by part number: 8603209
|
| 58. |
80300388
|
[5] |
SCREW,M12 x 25mm
|
ZED
Cap, HH, CL 8.8, M12 x 1.75 x 25 Superseded by part number: 300388
|
| 60. |
84100489
|
[1] |
DISC
|
ZED
|
