凯斯零件查询(LBX332P) - BIG RECTANGULAR BALER ''PACKER CUTTER'' (3/03-12/08) (13.17[01]) - KNIVES Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
420 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
84056426
|
[6] |
KNIFE
|
ZED
|
| 1. |
84058221
|
[6] |
KNIFE
|
ZED
|
| 1. |
84042300
|
[6] |
KNIFE
|
ZED
|
| 2. |
84042301
|
[6] |
COVER PLATE
|
ZED
|
| 3. |
84437837
|
[3] |
PLATE
|
ZED
|
| 4. |
89706687
|
[15] |
SCREW
|
ZED
M12 x 30 Superseded by part number: 9706687
|
| 5. |
80140046
|
[22] |
WASHER
|
ZED
12.4 MM Superseded by part number: 140046
|
| 6. |
89511052
|
[6] |
WASHER
|
ZED
12 MM Superseded by part number: 9511052
|
| 7. |
80180043
|
[1] |
COTTER PIN
|
ZED
Superseded by part number: 180043
|
| 8. |
89706685
|
[12] |
NUT
|
ZED
M12 Superseded by part number: 9706685
|
| 9. |
80043129
|
[1] |
SCREW
|
ZED
Cap, HH, CL 8.8, M8 x 1.25 x 40 Superseded by part number: 16044024
|
| 10. |
80322358
|
[1] |
LOCK WASHER
|
ZED
8.2 MM Superseded by part number: 322358
|
| 11. |
80140016
|
[1] |
WASHER
|
ZED
9 MM Superseded by part number: 86624184
|
| 12. |
CUR80000322
|
[2] |
8.7 MM
|
CHANNEL
|
| 13. |
89706690
|
[1] |
NUT,M8, Cl 8
|
ZED
Superseded by part number: 43362
|
| 14. |
84039271
|
[1] |
SHAFT
|
ZED
|
| 15. |
80140223
|
[1] |
WASHER
|
ZED
13 MM Superseded by part number: 140223
|
| 16. |
84814911
|
[1] |
SPRING
|
ZED
|
| 17. |
80394549
|
[1] |
HANDLE
|
ZED
Superseded by part number: 394549
|
| 18. |
80130003
|
[1] |
COTTER PIN
|
ZED
Superseded by part number: 130003
|
| 19. |
84039344
|
[2] |
COVER PLATE
|
ZED
|
| 20. |
84053769
|
[12] |
SPRING
|
ZED
|
| 21. |
84042026
|
[6] |
LEVER
|
ZED
|
| 22. |
80356731
|
[6] |
BUSHING
|
ZED
Superseded by part number: 356731
|
| 23. |
80043140
|
[6] |
BOLT,M10 x 1.5 x 30mm, Cl 8.8
|
ZED
Superseded by part number: 43140
|
| 24. |
84041862
|
[6] |
CIRCLIP
|
ZED
|
| 25. |
84039341
|
[6] |
ROLLER
|
ZED
|
| 26. |
84043787
|
[6] |
PIN
|
ZED
Superseded by part number: 87652359
|
| 27. |
84041615
|
[1] |
SHAFT
|
ZED
|
| 28. |
89837937
|
[1] |
SCREW
|
ZED
M12 x 100 Superseded by part number: 9837937
|
| 29. |
80370008
|
[2] |
SNAP RING,M50, Ext
|
ZED
Superseded by part number: 8603209
|
| 30. |
84043554
|
[1] |
SUPPORT
|
ZED
|
| 31. |
84043555
|
[1] |
LEVER
|
ZED
|
| 32. |
100016
|
[2] |
NUT,M10 x 1.5, Cl 8
|
NH
|
| 33. |
80140045
|
[2] |
WASHER
|
ZED
Belleville, 10.2 MM Superseded by part number: 140045
|
| 34. |
86512446
|
[2] |
CARRIAGE BOLT,M10 x 1.5 x 30mm, Cl 8.8
|
NH
|
| 35. |
84110679
|
[1] |
DIA KIT, HARVESTER
|
ATT
(1) Superseded by part number: 84058221
|
