| 1. |
84818577
|
[1] |
FRAME
|
ZED
, Serial Range: -C655
|
| 1. |
87682608
|
[1] |
CHANNEL
|
ZED
, Start Serial: D656
|
| 2. |
80140048
|
[1] |
WASHER
|
ZED
16 MM Superseded by part number: 140048
|
| 3. |
86000441
|
[1] |
NUT,M16 x 2.0, Cl 8
|
NH
|
| 4. |
80043168
|
[1] |
BOLT
|
ZED
M16 x 40 Superseded by part number: 43168
|
| 5. |
80394631
|
[1] |
WASHER
|
ZED
16 MM Superseded by part number: 394631
|
| 6. |
86508568
|
[5] |
BOLT,Hex, M6 x 1 x 16mm, Cl 8.8
|
NH
|
| 7. |
80322357
|
[5] |
LOCK WASHER,Belleville, M6
|
ZED
Superseded by part number: 322357
|
| 8. |
89706685
|
[1] |
NUT
|
ZED
M12 Superseded by part number: 9706685
|
| 9. |
80043127
|
[1] |
SCREW,M8 x 25mm
|
ZED
Superseded by part number: 43127
|
| 10. |
80322358
|
[1] |
LOCK WASHER
|
ZED
8 MM Superseded by part number: 322358
|
| 11. |
89706690
|
[1] |
NUT,M8, Cl 8
|
ZED
Superseded by part number: 43362
|
| 12. |
80308761
|
[1] |
SCREW,M8 x 25mm
|
ZED
M8 x 25 Superseded by part number: 308761
|
| 13. |
89839087
|
[1] |
RING
|
ZED
Superseded by part number: 9839087
|
| 14. |
84818961
|
[1] |
SHIELD
|
ZED
|
| 15. |
84074993
|
[1] |
GUIDE
|
ZED
|
| 16. |
89837806
|
[1] |
BEARING ASSY
|
ZED
Superseded by part number: 9837806
|
| 17. |
120104
|
[1] |
BOLT,Hex, M8 x 1.25 x 20mm, Cl 8.8
|
NH
|
| 18. |
80300389
|
[1] |
BOLT,M12 x 35mm
|
ZED
M12 x 35 Superseded by part number: 628-12035
|
| 19. |
84005089
|
[2] |
STOP,M8 x 1.25 x 50mm, Rubber
|
ZED
|
| 20. |
84100500
|
[1] |
PLATE
|
ZED
|
| 21. |
80378245
|
[1] |
WASHER
|
ZED
12 MM Superseded by part number: 378245
|
| 22. |
412183
|
[1] |
CARRIAGE BOLT,Short Sq Nk, M10 x 35mm, Cl 8.8
|
DUB
Superseded by part number: 9833222
|
| 23. |
80140045
|
[1] |
WASHER
|
ZED
Belleville, M10 Superseded by part number: 140045
|
| 24. |
100016
|
[1] |
NUT,M10 x 1.5, Cl 8
|
NH
|
| 25. |
140046
|
[1] |
BELLEVILLE WASHER,M12 Bolt Size x 27mm OD x 1.8mm Thk
|
NH
|
| 26. |
86595832
|
[2] |
CARRIAGE BOLT,Sht Sq Nk, M16 x 40mm, Cl 8.8, Full Thd
|
NH
, Start Serial: D656
|
| 27. |
100020
|
[2] |
NUT,M16 x 2.0, Cl 8
|
NH
, Start Serial: D656
|
