| 1. |
80120044
|
[2] |
BOLT
|
ZED
M12 x 30 Superseded by part number: 120044
|
| 2. |
89838297
|
[2] |
CLEVIS
|
ZED
Superseded by part number: 9838297
|
| 3. |
89706685
|
[4] |
NUT
|
ZED
M12 Superseded by part number: 9706685
|
| 4. |
89839262
|
[1] |
ROD
|
ZED
Superseded by part number: 9839262
|
| 5. |
84814727
|
[1] |
LEVER
|
ZED
|
| 6. |
80100037
|
[4] |
NUT,M10 x 1.5, Class 8
|
ZED
Superseded by part number: 100037
|
| 7. |
80140042
|
[1] |
WASHER
|
ZED
10 MM Superseded by part number: 140042
|
| 8. |
80140045
|
[1] |
WASHER
|
ZED
Belleville, M10 Superseded by part number: 140045
|
| 9. |
43138
|
[1] |
BOLT,Hex, M10 x 1.5 x 20mm, Cl 8.8
|
NH
|
| 10. |
84817403
|
[1] |
WASHER,25.5mm ID x 40mm OD x 2.5mm Thk
|
ZED
|
| 11. |
84074872
|
[1] |
HINGE
|
ZED
|
| 12. |
80140046
|
[2] |
WASHER
|
ZED
12 MM Superseded by part number: 140046
|
| 13. |
80301615
|
[1] |
RING
|
ZED
Superseded by part number: 800-1115
|
| 14. |
84019187
|
[1] |
ROLLER BEARING,15mm ID x 40mm OD x 15.9mm W
|
ZED
|
| 15. |
89706704
|
[2] |
BOLT,M10 x 35mm
|
ZED
M10 x 35 Superseded by part number: 9706704
|
| 16. |
80190029
|
[1] |
RUBBER BUMPER
|
ZED
Superseded by part number: 84440416
|
| 17. |
84078065
|
[3] |
SHIM,30mm OD x 5mm Thk
|
ZED
|
| 18. |
100016
|
[3] |
NUT,M10 x 1.5, Cl 8
|
NH
|
| 20. |
89839231
|
[2] |
WASHER
|
ZED
11 MM Superseded by part number: 9839231
|
| 21. |
89706690
|
[2] |
NUT,M8, Cl 8
|
ZED
Superseded by part number: 43362
|
| 22. |
84022964
|
[1] |
SUPPORT
|
ZED
|
| 23. |
80043139
|
[2] |
BOLT,M10 x 25mm
|
ZED
Superseded by part number: 11106231
|
| 24. |
89839261
|
[2] |
STOP
|
ZED
Superseded by part number: 9839261
|
| 25. |
89839275
|
[2] |
SPRING
|
ZED
Attach to 84074558 Support Superseded by part number: 9839275
|
| 26. |
80170025
|
[1] |
KEY
|
ZED
Superseded by part number: 170025
|
| 27. |
84078056
|
[1] |
ARM
|
ZED
|
| 28. |
80140041
|
[1] |
WASHER
|
ZED
Superseded by part number: 87033737
|
| 29. |
84038526
|
[1] |
BEARING CARRIER,25mm ID
|
ZED
|
| 30. |
84078058
|
[1] |
FORK
|
ZED
|
| 30. |
84817225
|
[1] |
GUIDE
|
ZED
|
| 31. |
84019645
|
[1] |
COVER
|
ZED
|
| 31. |
84019642
|
[1] |
COVER
|
ZED
|
| 32. |
84019644
|
[1] |
COVER PLATE
|
ZED
|
| 32. |
84019641
|
[1] |
COVER PLATE
|
ZED
|
| 33. |
89706703
|
[1] |
BOLT
|
ZED
M6 x 20 Superseded by part number: 9706703
|
| 34. |
80322357
|
[1] |
LOCK WASHER,Belleville, M6
|
ZED
Superseded by part number: 322357
|
| 35. |
15896221
|
[1] |
NUT,Hex, M6, 5.20mm High, Cl 10
|
ZED
Superseded by part number: 86500688
|
| 36. |
84320579
|
[1] |
BEARING HOUSING
|
ZED
|
| 37. |
80325103
|
[1] |
BALL BEARING
|
ZED
Superseded by part number: 325103
|
| 38. |
80120075
|
[2] |
SCREW
|
ZED
M10 x 100 Superseded by part number: 120075
|
| 39. |
80322358
|
[2] |
LOCK WASHER
|
ZED
8 MM Superseded by part number: 322358
|
