| 1. |
84074197
|
[1] |
SUPPORT
|
ZED
|
| 2. |
86508583
|
[12] |
BOLT,Hex, M16 x 35mm, Cl 8.8, Full Thd
|
NH
Superseded by part number: 86529976
|
| 3. |
80394631
|
[1] |
WASHER
|
ZED
16 MM Superseded by part number: 394631
|
| 4. |
80140048
|
[1] |
WASHER
|
ZED
16 MM Superseded by part number: 140048
|
| 5. |
86000441
|
[1] |
NUT,M16 x 2.0, Cl 8
|
NH
|
| 6. |
89706685
|
[1] |
NUT
|
ZED
M12 Superseded by part number: 9706685
|
| 7. |
80043127
|
[1] |
SCREW,M8 x 25mm
|
ZED
Cap, HH, CL 8.8, M8 x 1.25 x 25 Superseded by part number: 43127
|
| 8. |
80120090
|
[8] |
SCREW
|
ZED
M16 x 50 Superseded by part number: 120090
|
| 9. |
84038871
|
[1] |
SUPPORT
|
ZED
|
| 10. |
84062685
|
[7] |
GUIDE
|
ZED
, Serial Range: -C547
|
| 10. |
87392780
|
[7] |
GUIDE
|
ZED
, Serial Range: -F548655
|
| 10. |
87682542
|
[1] |
GUIDE
|
ZED
, Start Serial: D656
|
| 11. |
84038868
|
[1] |
ROD
|
ZED
|
| 12. |
80300423
|
[2] |
COTTER PIN
|
ZED
Superseded by part number: 300423
|
| 13. |
80140045
|
[1] |
WASHER
|
ZED
Belleville, M10 Superseded by part number: 140045
|
| 14. |
100016
|
[1] |
NUT,M10 x 1.5, Cl 8
|
NH
|
| 15. |
43138
|
[1] |
BOLT,Hex, M10 x 1.5 x 20mm, Cl 8.8
|
NH
|
| 16. |
84818579
|
[1] |
SHAFT
|
ZED
|
| 17. |
84073277
|
[1] |
PLATE
|
ZED
|
| 18. |
84607485
|
[3] |
PLATE
|
ZED
Middle
|
| 19. |
84607490
|
[3] |
PLATE
|
ZED
Middle
|
| 20. |
80322358
|
[1] |
LOCK WASHER
|
ZED
8 MM Superseded by part number: 322358
|
| 21. |
89706690
|
[1] |
NUT,M8, Cl 8
|
ZED
Superseded by part number: 43362
|
| 22. |
80338949
|
[1] |
CARRIAGE BOLT
|
ZED
Short Neck, CL 8.8, M10 x 1.5 x 25 Superseded by part number: 338949
|
| 23. |
84068986
|
[1] |
SUPPORT
|
ZED
(30), Serial Range: -C439
|
| 23. |
84801004
|
[1] |
SUPPORT
|
ZED
(30), Start Serial: D440
|
| 24. |
84078470
|
[1] |
PLATE
|
ZED
|
| 25. |
86507486
|
[1] |
CARRIAGE BOLT,M8 x 1.25 x 20mm, Cl 8.8
|
NH
|
| 25. |
80308761
|
[1] |
SCREW,M8 x 25mm
|
ZED
M8 x 25 Superseded by part number: 308761
|
| 25. |
86512443
|
[1] |
CARRIAGE BOLT,Sht Nk, M8 x 35mm, Cl 8.8, Full Thd
|
ZED
|
| 26. |
84607491
|
[7] |
PLATE
|
ZED
|
| 27. |
84069248
|
[70] |
RIVET,Pop, 4.8mm OD x 20.7mm L
|
ZED
RIVET
|
| 28. |
84607487
|
[7] |
STIFFENER
|
ZED
|
| 30. |
84068687
|
[4] |
SCRAPER BLADE
|
ZED
|
| 33. |
84068936
|
[1] |
PLUG
|
ZED
, Serial Range: -C383
|
| 33. |
84004713
|
[1] |
BUSHING,10.5mm ID x 25mm OD x 18mm L
|
ZED
, Start Serial: D384
|
| 34. |
43140
|
[2] |
BOLT,Hex, M10 x 1.5 x 30mm, Cl 8.8
|
NH
|
| 35. |
43465
|
[2] |
CARRIAGE BOLT,Short NK, M8 x 30, Cl8.8, Full Thd
|
NH
Superseded by part number: 811-8030
|
| 36. |
120090
|
[4] |
BOLT,Hex, M16 x 50mm, Cl 8.8
|
NH
, Serial Range: -C655
|
| 36. |
84053391
|
[4] |
CARRIAGE BOLT,Short NK, M12 x 130, Cl8.8
|
ZED
, Start Serial: D656
|
