神钢零件查询(K935) - EXCAVATOR SUPPLEMENT ASN LU00154 (1/76-12/03) (02-018) - GUARD ASSY, VANDLISM (FOR NORTH AMERICA) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
363 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24100J5657F1 | [1] | GUARD ASSY, Serial Range: LR.0183-LR.0223 | GUARD ASSY, Serial Range: LR.0183-LR.0223 |
| . . | 24100J5657F2 | [1] | GUARD ASSY, Start Serial: LR.0224 | |
| . . | 2414P3575 | [1] | GUARD | KOB |
| 2. | 2414P2923 | [1] | GUARD | KOB, Serial Range: LR.0183-LR.0223 |
| 3. | 2414P2924 | [1] | GUARD | KOB |
| 4. | 2414P2922 | [1] | GUARD | GUARD |
| 5. | 2414P2925 | [1] | GUARD | GUARD |
| 6. | 2414P2919 | [1] | GUARD | GUARD |
| 7. | 2414P2921 | [1] | GUARD | GUARD |
| 8. | 2414P2877 | [1] | GUARD | GUARD |
| 9. | 2432T1439 | [8] | CLAMP | KOB, Serial Range: LR.0183-LR.0223 |
| 10. | 2432T1440 | [4] | CLAMP | KOB |
| 11. | 2418T5373C2 | [12] | WASHER | KOBID 11 x OD 30 x Th 3.20mm Superseded by part number: 2418T12346 |
| 12. | R16T0137D3 | [12] | WASHER | KOBCone Disk Spring -- ID 10.2 x OD 20 x Th 0.8mm |
| 13. | 2420T3968 | [12] | BOLT | KOB |
| 14. | 2414P2962 | [1] | GUARD | KOB, Start Serial: LR.0224 |
| 15. | 2432T1816D1 | [1] | CLAMP | KOB, Start Serial: LR.0224 |
| 16. | 2432T1816D2 | [1] | CLAMP | KOB, Start Serial: LR.0224 |
| 17. | 2427J1781 | [1] | CAB, Start Serial: LR.0224 | |
