神钢零件查询(K935) - EXCAVATOR SUPPLEMENT ASN LU00154 (1/76-12/03) (02-021) - MAT, FLOOR (FOR NORTH AMERICA) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
610 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | LU718-001 | [1] | MAT, FLOOR (NA), Serial Range: LU.0057--LU.107 | |
| . . | LU718-002 | [1] | MAT, FLOOR, Start Serial: LU.010E- | |
| 1. | 2427R537 | [1] | MAT, FLOOR, Serial Range: LU.0097--LU.107 | |
| 1. | 2427R556 | [1] | MAT, FLOOR, Start Serial: Lu.0108- | MAT, FLOOR, Start Serial: Lu.0108- |
| 2. | 2427R538 | [1] | MAT, FLOOR, Serial Range: LU.0097--LU.107 | |
| 2. | 2427R557 | [1] | MAT, FLOOR, Start Serial: LU.OIO8- | MAT, FLOOR, Start Serial: LU.OIO8- |
