| 1. |
84074870
|
[2] |
SUPPORT,100 mm ID x 52 mm
|
ZED
|
| 1. |
84074868
|
[2] |
BEARING HOUSING,120 mm ID x 65 mm
|
ZED
|
| 2. |
80370026
|
[4] |
CIRCLIP
|
ZED
Superseded by part number: S301572
|
| 2. |
80412270
|
[4] |
SNAP RING
|
ZED
Superseded by part number: 412270
|
| 3. |
84000584
|
[4] |
SPACER,55mm ID x 85mm OD x 16mm L
|
ZED
|
| 3. |
89838119
|
[4] |
WASHER, THRUST
|
ZED
Superseded by part number: 9838119
|
| 4. |
84004409
|
[4] |
SEAL,85mm ID x 100mm OD x 9mm Thk
|
ZED
|
| 4. |
89838315
|
[4] |
GASKET
|
ZED
Superseded by part number: 9838315
|
| 5. |
84045245
|
[2] |
DISC
|
ZED
|
| 6. |
84004413
|
[4] |
SCREW,M14 x 70mm, Cl 8.8
|
ZED
M14 x 70
|
| 6. |
89838120
|
[4] |
SCREW
|
ZED
M16 x 70 Superseded by part number: 9838120
|
| 7. |
80120079
|
[4] |
BOLT
|
ZED
M12 x 40 Superseded by part number: 86629541
|
| 8. |
84000586
|
[1] |
CROSSRAIL
|
ZED
Superseded by part number: 47822182
|
| 8. |
89838114
|
[1] |
ANGLE BAR
|
ZED
Superseded by part number: 47822090
|
| 9. |
84045246
|
[2] |
SHAFT
|
ZED
|
| 9. |
84045247
|
[2] |
SHAFT
|
ZED
|
| 10. |
89516384
|
[2] |
BEARING ASSY
|
ZED
Superseded by part number: 9516384
|
| 10. |
89838113
|
[2] |
BEARING ASSY
|
ZED
Superseded by part number: 9838113
|
| 11. |
84000588
|
[2] |
LINK CONROD
|
ZED
, Serial Range: -C595 Superseded by part number: 87664702
|
| 11. |
87664702
|
[2] |
LINK CONROD
|
ZED
, Start Serial: D596
|
| 11. |
89838110
|
[2] |
LINK CONROD
|
ZED
, Serial Range: -C595 Superseded by part number: 87664701
|
| 11. |
87664701
|
[2] |
LINK CONROD
|
ZED
, Start Serial: D596
|
| 12. |
84000581
|
[1] |
ADJUSTING PLATE
|
ZED
|
| 12. |
89838109
|
[1] |
ADJUSTING PLATE
|
ZED
Superseded by part number: 9838109
|
| 13. |
100019
|
[4] |
NUT,M14, Cl 8
|
NNA
Superseded by part number: 86508817, 86508817, NLS
|
| 13. |
9505933
|
[4] |
NUT,M16 x 2, Cl 12
|
ZED
Superseded by part number: 89505933
|
| 14. |
84011662
|
[8] |
WASHER,14mm ID x 32mm OD x 3.5mm Thk
|
ZED
14 MM
|
| 14. |
80394631
|
[8] |
WASHER
|
ZED
17 MM Superseded by part number: 394631
|
| 15. |
440419
|
[4] |
BOLT,Hex, M14 x 2 x 55mm, Cl 8.8, Full Thd
|
NH
Superseded by part number: 86523012
|
| 15. |
80412398
|
[4] |
SCREW
|
ZED
M16 x 50 Superseded by part number: 412398
|
| 16. |
84045248
|
[2] |
LOCKING PLATE
|
ZED
|
