| 1. |
84800679
|
[1] |
PLUNGER
|
ZED
Superseded by part number: 394632, 84470773, 84488254, 84469721, 84498844, 84498751, 84470780, 47470788
|
| 1. |
84817022
|
[1] |
PLUNGER
|
ZED
Superseded by part number: 84498844, 84498751, 84470769, 84470767, 394632, 47470788, 84488254, 84469719
|
| 1. |
84442120
|
[1] |
PLUNGER
|
ZED
Superseded by part number: 394632, 47470788, 84470780, 84469718, 84498844, 84498751, 84470773, 84488255
|
| 1. |
84817021
|
[1] |
PLUNGER
|
ZED
Superseded by part number: 84498844, 84498751, 84488255, 394632, 84470767, 47470788, 84469708, 84470769
|
| 2. |
84441921
|
[2] |
SUPPORT
|
ZED
|
| 3. |
84817041
|
[1] |
SHIM
|
ZED
Superseded by part number: 84817042
|
| 4. |
84817043
|
[6] |
SHIM
|
ZED
Superseded by part number: 84817044
|
| 5. |
84814869
|
[3] |
KNIFE,108mm L x 68mm W x 10mm Thk
|
ZED
|
| 5. |
84814868
|
[5] |
KNIFE,116mm L x 68mm W x 10mm Thk
|
ZED
|
| 6. |
84814870
|
[2] |
KNIFE,90mm L x 68mm W x 10mm Thk
|
ZED
|
| 7. |
84819017
|
[3] |
ANTI-WRAP PLATE
|
ZED
, Serial Range: -C547
|
| 7. |
87523579
|
[3] |
SCRAPER
|
ZED
, Start Serial: D548
|
| 7. |
84441920
|
[5] |
ANTI-WRAP PLATE
|
ZED
, Serial Range: -C547
|
| 7. |
87523571
|
[5] |
SCRAPER
|
ZED
, Start Serial: D548
|
| 8. |
84447646
|
[1] |
ANTI-WRAP PLATE
|
ZED
RH
|
| 9. |
84819013
|
[1] |
ANTI-WRAP PLATE
|
ZED
LH
|
| 10. |
84818503
|
[2] |
ANTI-WRAP PLATE
|
ZED
LH + RH, Serial Range: -C411 Superseded by part number: 84801186
|
| 10. |
84801186
|
[1] |
ANTI-WRAP PLATE
|
ZED
RH, Start Serial: D412
|
| 11. |
84818501
|
[1] |
ANTI-WRAP PLATE
|
ZED
RH, Serial Range: -C411 Superseded by part number: 84801359
|
| 11. |
84801359
|
[1] |
ANTI-WRAP PLATE
|
ZED
RH, Start Serial: D412
|
| 12. |
84447644
|
[1] |
ANTI-WRAP PLATE
|
ZED
LH, Serial Range: -C411 Superseded by part number: 84801361
|
| 12. |
84801361
|
[1] |
ANTI-WRAP PLATE
|
ZED
LH, Start Serial: D412
|
| 13. |
84441919
|
[1] |
ANTI-WRAP PLATE
|
ZED
|
| 14. |
84441749
|
[1] |
CAM
|
ZED
|
| 15. |
84441748
|
[4] |
SUPPORT
|
ZED
|
| 16. |
89838081
|
[2] |
ROLLER
|
ZED
, Serial Range: -C699 Superseded by part number: 861325
|
| 16. |
861325
|
[2] |
BEARING ASSY,0.75" ID x 2.5" OD x 2.25"
|
NH
, Start Serial: D700
|
| 17. |
84814846
|
[1] |
SHAFT
|
ZED
|
| 18. |
84814847
|
[3] |
SHAFT
|
ZED
|
| 19. |
84100796
|
[4] |
ROLLER,72mm OD x 29mm L
|
ZED
|
| 20. |
89838305
|
[4] |
WASHER
|
ZED
Superseded by part number: 9838305
|
| 21. |
80380420
|
[1] |
BOLT
|
ZED
M12 x 40 Superseded by part number: 380420
|
| 22. |
80140046
|
[1] |
WASHER
|
ZED
12 MM Superseded by part number: 140046
|
| 23. |
89706685
|
[1] |
NUT
|
ZED
M12 Superseded by part number: 9706685
|
| 24. |
80140045
|
[1] |
WASHER
|
ZED
Superseded by part number: 140045
|
| 25. |
89706704
|
[1] |
BOLT,M10 x 35mm
|
ZED
Superseded by part number: 9706704
|
| 26. |
80100037
|
[1] |
NUT,M10 x 1.5, Class 8
|
ZED
, Serial Range: -C547 Superseded by part number: 100037
|
| 26. |
100016
|
[1] |
NUT,M10 x 1.5, Cl 8
|
NH
, Start Serial: D548
|
| 27. |
80043139
|
[1] |
BOLT,M10 x 25mm
|
ZED
Superseded by part number: 11106231
|
| 28. |
86592700
|
[1] |
WASHER,10.5mm ID x 28mm OD x 4mm Thk
|
ZED
, Serial Range: -C423
|
| 28. |
80140083
|
[1] |
WASHER
|
ZED
, Start Serial: D424 Superseded by part number: 140083
|
| 29. |
84064578
|
[4] |
BUSHING,16.5mm ID x 32mm OD x 12.5mm L
|
ZED
|
| 30. |
80140048
|
[4] |
WASHER
|
ZED
Superseded by part number: 140048
|
| 31. |
80412185
|
[4] |
BOLT
|
ZED
Superseded by part number: 412185
|
| 32. |
100020
|
[4] |
NUT,M16 x 2.0, Cl 8
|
NH
, Serial Range: -C547
|
| 32. |
392530
|
[4] |
NUT,M16, Cl 10
|
NH
, Start Serial: D548
|
| 33. |
80322359
|
[2] |
LOCK WASHER
|
ZED
Superseded by part number: 322359
|
| 34. |
100033
|
[4] |
THIN NUT,Thin, M24 x 1.5, Cl 04
|
ZED
|
| 35. |
80300388
|
[4] |
SCREW,M12 x 25mm
|
ZED
Superseded by part number: 300388
|
| 36. |
80374895
|
[1] |
CARRIAGE BOLT
|
ZED
Superseded by part number: 374895
|
| 37. |
80543043
|
[1] |
WASHER
|
ZED
Superseded by part number: 543043
|
| 38. |
84818499
|
[1] |
ANTI-WRAP PLATE
|
ZED
RH, Serial Range: -C411 Superseded by part number: 84801196
|
| 38. |
84801196
|
[1] |
SCRAPER BLADE
|
ZED
RH, Start Serial: D412
|
| 39. |
84447641
|
[1] |
ANTI-WRAP PLATE
|
ZED
LH, Serial Range: -C411 Superseded by part number: 84801194
|
| 39. |
84801194
|
[1] |
SCRAPER BLADE
|
ZED
LH, Start Serial: D412
|
| 40. |
80001689
|
[2] |
NUT
|
ZED
|
| 41. |
84429747
|
[1] |
GUIDE
|
ZED
LH
|
| 41. |
84429787
|
[1] |
GUIDE
|
ZED
RH
|
| 41. |
84800583
|
[3] |
GUIDE
|
ZED
Middle, LH
|
| 41. |
84800581
|
[3] |
GUIDE
|
ZED
Middle, RH
|
| 42. |
84814537
|
[1] |
KNIFE,630mm L x 60mm W x 10mm Thk
|
ZED
LH
|
| 43. |
84607550
|
[1] |
GUIDE
|
ZED
|
| 44. |
84400465
|
[1] |
KNIFE
|
ZED
|
| 44. |
84814538
|
[1] |
KNIFE,540mm L x 60mm W x 10mm Thk
|
ZED
RH
|
| 45. |
80328754
|
[1] |
SCREW
|
ZED
Superseded by part number: 328754
|
| 47. |
86629541
|
[1] |
BOLT,Hex, M12 x 1.75 x 40mm, Cl 8.8
|
NH
|
| 48. |
84021078
|
[2] |
COVER
|
ZED
|
| 49. |
80322357
|
[4] |
LOCK WASHER,Belleville, M6
|
ZED
Superseded by part number: 322357
|
| 50. |
84814892
|
[4] |
WING NUT,M6 x 1.0
|
ZED
|
| 51. |
84801357
|
[2] |
PLATE
|
ZED
, Start Serial: D412
|
| 52. |
84801556
|
[1] |
SCRAPER BLADE
|
ZED
LH, Start Serial: D424
|
| 53. |
140045
|
[1] |
BELLEVILLE WASHER,M10 Bolt Size x 22mm OD x 1.6mm Thk
|
NH
, Serial Range: -C547
|
| 53. |
140083
|
[1] |
WASHER,11mm ID x 40mm OD x 6mm Thk
|
ZED
, Start Serial: D548
|
| 54. |
87600336
|
[1] |
PLATE
|
ZED
, Start Serial: D584
|
