纽荷兰零件查询(E70SR) - MIDI CRAWLER EXCAVATOR ASN YT04-07175 (05-009) - LIGHT INSTAL (5 LIGHT) New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
856 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YT80E00006F3 | [1] | LIGHT INSTAL | |
| 6. | 2479U1190F1 | [1] | SWITCH | KOBASSY |
| 13. | PY01P01043D2 | [2] | CABLE TIE,4.60mm W x 202mm L | KOBWire Ties -- 160mm Long Superseded by part number: YT50C01100P1 |
| 15. | 2432R233D3 | [1] | CLIP | KOB |
| 16. | ZM22C10030 | [1] | BOLT | KOBM10x1.50x30mm (Incls. Washer & Lockwasher) |
| 17. | 2418R323D11 | [1] | WASHER | KOB |
| 18. | YT80E01002P1 | [1] | HARNESS | KOB |
