纽荷兰零件查询(E70SR) - MIDI CRAWLER EXCAVATOR ASN YT04-07175 (05-012) - HEATER ASSY, P/N YT21M00004F1 New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
798 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YT21M00004F1 | [1] | HEATER ASSY (WITH HEATER) | |
| . . | YT21M00004F2 | [1] | HEATER ASSY (WITHOUT HEATER) | |
| 1. | 2479U293D4 | [1] | HEATER | KOBASSY, (F1 ONLY), SEE FIG. 05-013 |
| 2. | 2479U325 | [1] | SWITCH | KOB(F1 ONLY) |
| 5. | YT20M01082P1 | [1] | SUPPORT | KOB |
| 6. | YT21M01006P1 | [1] | RUBBER | KOB |
| 7. | YT21M01002P1 | [1] | SUPPORT | KOB(F1 ONLY) |
| 11. | YT21M01001P1 | [1] | PANEL | KOBPANEL |
| 12. | ZM61C06012 | [4] | BOLT | KOBSEMS |
| 13. | YT14E01015P1 | [1] | WIRE HARNESS | KOB(F1 ONLY) |
| 14. | YR21M01017P1 | [1] | GROMMET | KOB(F1 ONLY) |
| 16. | ZM22C08020 | [8] | BOLT | KOBSEMS, (F1 ONLY) |
| 17. | ZM22C10025 | [4] | BOLT | KOBSEMS |
| 18. | 2420R1089D1 | [4] | BOLT,M5 x 10mm | KOBSEMS |
| 19. | 2420Z1220 | [1] | GROMMET | KOB(F2 ONLY) |
| 20. | YT03M01038P1 | [1] | SUPPORT | KOB |
| 21. | YT03M01004P1 | [1] | SUPPORT | KOB |
| 22. | YT21M01004P1 | [2] | GROMMET | KOB |
| 23. | YT20M01083P1 | [1] | SUPPORT | KOB |
| 24. | PH17M01011P1 | [1] | LABEL | KOB(F2 ONLY) |
