纽荷兰零件查询(E70SR) - MIDI CRAWLER EXCAVATOR ASN YT04-07175 (05-011) - HOSE ASSY, HEATER New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
200 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YT21M00001F1 | [1] | HOSE ASSY, HEATER | |
| 1. | R18T0026D17 | [1] | HOSE | KOB |
| 2. | YN20M01046DE | [1] | TUBE,22.10mm ID x 27.00mm OD x 2300.00mm | KOBProtective Plastic Superseded by part number: YN20M01427DA |
| 3. | YN20M01046D3 | [2] | TUBE,22.10mm ID x 27.00mm OD x 800.00mm | KOBProtective Plastic |
| 4. | ZS18C10020 | [1] | SCREW,Hex, M10 x 20mm | KOBCap |
| 5. | PH21M01008P1 | [1] | COCK | KOB |
| 6. | YT21M01007P1 | [1] | CONNECTION | KOB |
| 9. | ZC16X02000 | [4] | CLIP | KOB |
| 10. | ZW16X10000 | [2] | WASHER | KOB |
| 11. | 2432R225D11 | [2] | CLIP | KOB Superseded by part number: ZC46X29011 |
| 12. | YR21M01017P1 | [1] | GROMMET | KOB |
| 13. | YT20M01086P1 | [1] | GROMMET | KOB |
| 14. | ZN18C10008 | [1] | NUT | KOBM10x1.50mm |
| 15. | R18T0026D42 | [1] | HOSE | KOB |
| 16. | YN20M01046D9 | [1] | TUBE,22.10mm ID x 27.00mm OD x 1700.00mm | KOBProtective Plastic |
| 17. | 2444Z2220D18 | [1] | HOSE | KOB |
| 18. | YN20M01094DA | [1] | TUBE,25mm ID x 30mm OD x 100mm Length | KOB |
| 19. | ZC16X02400 | [2] | CLIP | KOB |
| 20. | 2418T10455 | [1] | PIPE | KOB |
| 21. | PY01P01043D5 | [1] | CABLE TIE,301mm L | KOB |
