纽荷兰零件查询(E70SR) - MIDI CRAWLER EXCAVATOR ASN YT04-07175 (05-018) - HYD LINES, BOOM 3.72M (BOOM & ARM SAFETY) New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
275 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YT42H00062F2 | [1] | HYD LINES, BOOM 3.72M | |
| 1. | 2420R537D320 | [1] | HOSE ASSY.,9.60mm ID x 3200mm L | KOB |
| 2. | 2444R1119D305 | [1] | HOSE | KOB |
| 3. | LF42H01009P1 | [1] | BRACKET | KOB |
| 5. | ZH22X06000 | [4] | HYD CONNECTOR | KOB |
| 6. | ZS18C10020 | [3] | SCREW,Hex, M10 x 20mm | KOBCap |
| 7. | ZW26X10000 | [3] | LOCK WASHER | KOBID 10 x OD 18 x Th 2.5mm |
| 8. | ZW16H10000 | [1] | WASHER | KOB |
| 9. | 2414Z199D100 | [3] | GUARD | KOBHOSE |
| 10. | ZC48X22014 | [1] | CLIP | KOB |
| 11. | PY01P01043D8 | [10] | CABLE TIE,102mm L | KOB |
