纽荷兰零件查询(E70SR) - MIDI CRAWLER EXCAVATOR ASN YT04-07175 (05-020) - ARM ASSY, LONG 2.07M New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
644 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YT12B00067F3 | [1] | ARM | KOBARM GROUP |
| A1. | YT12B01022F1 | [1] | LINK | KOBASSY, BUCKET |
| A1-1. | NSS | [1] | NOT SERVICED SEPARATELY | CONLINK, BUCKET |
| A1-2. | YR12B01079P1 | [1] | BUSHING | KOB |
| A1-3. | LE12B01055P1 | [1] | BUSHING | KOB |
| A2. | YT12B01023F1 | [1] | LINK ASSY. | KOBBUCKET |
| A3. | YT12B01016P1 | [1] | LINK | KOB Superseded by part number: YT12B01347P1 |
| A4. | YT12B01017P1 | [1] | LINK | KOB |
| A5. | YT12B01113P1 | [2] | PIN | KOB |
| A6. | YT12B01018P1 | [1] | PIN | KOB, Serial Range: YT04-07175-YT04-08982 Superseded by part number: YT12B01345P1 |
| A6. | YT12B01018P2 | [1] | PIN | KOB, Start Serial: YT04-08983 Superseded by part number: YT12B01345P1 |
| A7. | YT12B01019P1 | [1] | PIN | KOB Superseded by part number: YT12B01346P1 |
| A8. | HS18C12100G2 | [2] | SCREW | KOBM12x1.75x100mm |
| A9. | ZN18C12010 | [4] | NUT | KOB |
| A10. | 2445R138D19 | [6] | SEAL,50mm ID x 60mm OD x 4mm Thk | KOBDUST |
| A11. | 2445R220D1 | [2] | SEAL,60mm ID x 75mm OD x 5mm Thk | KOBDUST |
| A12. | 2445R220D5 | [4] | SEAL,50mm ID x 65mm OD x 5mm Thk | KOBDUST |
| A13. | ZG91S02000 | [6] | LUBE NIPPLE,1/8" NPT x 1/8" NPT | KOB |
| A15. | 2418T20767 | [1] | SPACER | KOB |
| A16. | B16T0442D41 | [6] | SHIM,80mm OD x 52mm ID x 0.9mm Thk | KOB |
| A17. | B16T0442D25 | [6] | SHIM,80mm OD x 52mm ID x 1.2mm Thk | KOB |
| A18. | YR12B01028P1 | [6] | SHIM | KOB(2.0) |
| A19. | B16T0442D54 | [6] | SHIM,52mm ID x 80mm OD x 0.5mm Thk | KOB |
| . . | YT12B00080F1 | [1] | ARM | KOBARM ASSY, LONG |
| B1-2. | YT12B01057P1 | [1] | PLATE | KOB |
| B2. | YT12B01010P2 | [2] | BUSHING | KOB |
| B3. | LE12B01054P1 | [2] | BUSHING | KOB |
| B4. | YT12B01112P1 | [2] | BUSHING | KOB |
| . . | YT12B00003F1 | [1] | ARM | KOBARM INSTAL (KAI) |
| . . | YT12B00003F2 | [1] | ARM INSTAL (EU) | |
| C1. | YT12B01037P1 | [1] | PIN | KOB |
| C2. | YT12B01015P1 | [1] | PIN | KOB(F1 ONLY) |
| C3. | HS18C14115G2 | [1] | BOLT,Hex, M14 x 115mm, Cl 10.9 | KOBCAP |
| C4. | ZN18C14011 | [2] | NUT | KOB |
| C5. | YR02B01266D3 | [2] | SHIM | KOB(0.5) |
| C6. | YR02B01266D1 | [2] | SHIM | KOB(0.9) |
| C7. | YR02B01265P1 | [2] | SHIM | KOB(2.0) |
| C8. | B16T0442D56 | [1] | SHIM,0.5mm Thk | KOB |
| C9. | B16T0442D43 | [1] | SHIM,0.9mm Thk | KOB |
| C10. | B16T0442D27 | [1] | SHIM,62mm ID x 100mm OD x 1.2mm Thk | KOB(1.2) |
| C11. | PY02B01028P1 | [2] | SHIM,2.0mm Thk | KOB |
| C12. | ZS18C12025 | [1] | SCREW,Hex, M12 x 25mm | KOBCAP |
| C13. | 2418T21942 | [1] | WASHER | KOB |
| C14. | ZW26X12000 | [1] | WASHER | KOB |
| C15. | YT12B01055P1 | [1] | PIN | KOB(F2 ONLY) |
