纽荷兰零件查询(E70SR) - MIDI CRAWLER EXCAVATOR ASN YT04-07175 (05-021) - HYD LINES, ARM 2.07M New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
510 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 0. | YT01V00019F1 | [1] | CYLINDER ASSY. | KOBBUCKET |
| . . | YT12B00005F2 | [1] | CYLINDER INSTAL | |
| A2. | HS18C12100G2 | [1] | SCREW | KOBM12x1.75x100mm |
| A3. | ZN18C12010 | [2] | NUT | KOB |
| A4. | B16T0442D54 | [1] | SHIM,52mm ID x 80mm OD x 0.5mm Thk | KOB |
| A5. | B16T0442D41 | [1] | SHIM,80mm OD x 52mm ID x 0.9mm Thk | KOB |
| A6. | B16T0442D25 | [1] | SHIM,80mm OD x 52mm ID x 1.2mm Thk | KOB |
| A7. | B16T0442D23 | [1] | SHIM,80mm OD x 52mm ID x 1.6mm Thk | KOB(1.6) |
| A8. | YR12B01028P1 | [2] | SHIM | KOB(2.0) |
| A9. | YT12B01054P1 | [1] | PIN | KOB |
| . . | YT43H00005F1 | [1] | LINE | KOBHYD LINES, CYLINDER |
| B1. | YT43H01005P1 | [1] | TUBE | KOB |
| B2. | YT43H01006P1 | [1] | TUBE | KOB |
| B3. | ZA23F22008 | [1] | HYD CONNECTOR | KOB |
| B4. | ZA33F22008 | [1] | ELBOW,M30 x 1.5 ORB x 1/2" NPT | KOB |
| B5. | YR43H01003P1 | [2] | CLAMP | KOB |
| B6. | ZS18C10050 | [2] | SCREW,Hex, M10 x 50mm | KOBCAP |
| B7. | ZW26X10000 | [2] | LOCK WASHER | KOBID 10 x OD 18 x Th 2.5mm |
| B8. | ZD12P01800 | [2] | O-RING | KOB |
| B9. | ZG91S02000 | [1] | LUBE NIPPLE,1/8" NPT x 1/8" NPT | KOB |
| B10. | ZG91U02000 | [1] | LUBE NIPPLE | KOB |
| . . | LF43H00005F1 | [1] | HYD LINES, ARM | |
| C1. | YT43H01013DB | [2] | HOSE | KOB |
