神钢零件查询(K935) - EXCAVATOR SUPPLEMENT ASN LU00154 (1/76-12/03) (02-046) - CATWALK Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
453 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24100N1753F1 | [1] | CATWALK LU.0086, Serial Range: 0096--LU.0145 | |
| . . | 24100N1753F3 | [1] | CATWALK, Start Serial: LU.0146- | |
| 1. | 2422P415 | [1] | CATWALK, Serial Range: LU.0086,0096--LU.0145 | |
| 2. | 2422P416 | [2] | CATWALK, Serial Range: LU.0086,0096--LU.0145 | |
| 3. | 2422P907 | [1] | CATWALK, Serial Range: LU.0086,0096--LU.0145 | |
| 4. | 2422P418 | [1] | CATWALK CATWALK, Serial Range: LU.0086,0096--LU.0145 | CATWALK CATWALK, Serial Range: LU.0086,0096--LU.0145 |
| 5. | 2416T7133 | [14] | BLOCK | KOBBLOCK, TAPPED |
| 7. | ZS18C16030 | [28] | SCREW,Hex, M16 x 30mm | KOBM16x2.0x30mm |
| 8. | ZW16H16000 | [28] | WASHER | KOBID 17 x OD 32 x Th 4.5mm |
| 9. | ZS18C12030 | [6] | SCREW,Hex, M12 x 30mm | KOBM12x1.75x30mm |
| 10. | ZN18C12010 | [6] | NUT | KOBM12x1.75mm |
| 11. | ZW16H12000 | [6] | WASHER | KOBID 13 x OD 26 x Th 3.2mm |
| 12. | 2420T3918D1 | [7] | SHIM, 1.2 SHIM 1.2 | SHIM, 1.2 SHIM 1.2 |
| 13. | 2420T3918D2 | [7] | SHIM, 1.6 | SHIM, 1.6 |
| 16. | 2427P3009 | [1] | CATWALK, Start Serial: LU.0146- | |
| 17. | 2427P3008 | [1] | CATWALK, Start Serial: LU.0146- | CATWALK, Start Serial: LU.0146- |
| 18. | 2427P3010 | [1] | CATWALK, Start Serial: LU.0146- | |
| 19. | 2427P3007 | [1] | CATWALK, Start Serial: LU.0146- | CATWALK, Start Serial: LU.0146- |
