84067143
|
[1] |
DIA KIT, HARVESTER
|
ATT
|
| 1. |
84320972
|
[2] |
SHOCK ABSORBER
|
ZED
|
| 2. |
84400063
|
[1] |
EXTENSION
|
ZED
|
| 3. |
84607217
|
[1] |
EXTENSION
|
ZED
|
| 4. |
84074166
|
[1] |
SUPPORT
|
ZED
|
| 5. |
84074168
|
[1] |
SUPPORT
|
ZED
|
| 6. |
9837933
|
[6] |
SPACER,17mm ID x 25.4mm OD x 12.5mm L
|
ZED
|
| 7. |
84320970
|
[1] |
SUPPORT
|
ZED
|
| 8. |
84074170
|
[2] |
CHAIN,1505mm L
|
ZED
|
| 9. |
9512549
|
[2] |
ROD
|
ZED
|
| 10. |
180043
|
[1] |
COTTER PIN
|
ZED
|
| 11. |
84320651
|
[1] |
SUPPORT
|
ZED
|
| 12. |
84074054
|
[2] |
SUPPORT
|
ZED
|
| 13. |
84074051
|
[4] |
SUPPORT
|
ZED
|
| 14. |
43167
|
[2] |
BOLT,Hex, M16 x 30mm, Cl 8.8, Full Thd
|
NH
|
| 15. |
378248
|
[1] |
WASHER,25mm ID x 50mm OD x 4mm Thk
|
ZED
|
| 16. |
381929
|
[1] |
LOCK PIN,M5 x 60, Slotted
|
ZED
Superseded by part number: 37428
|
| 17. |
378246
|
[4] |
WASHER,17mm ID x 34mm OD x 3mm Thk
|
ZED
|
| 18. |
9706690
|
[4] |
NUT,M8 x 1.25, Cl 8
|
NH
Superseded by part number: 43362
|
| 19. |
309308
|
[2] |
BOLT,Hex, M12 x 1.75 x 120mm, Cl 8.8
|
NH
|
| 20. |
140046
|
[8] |
BELLEVILLE WASHER,M12 Bolt Size x 27mm OD x 1.8mm Thk
|
NH
|
| 21. |
9706685
|
[6] |
NUT,M12 x 1.75, Cl 8
|
NH
|
| 22. |
120046
|
[2] |
CARRIAGE BOLT,M16 x 60mm, Cl 8.8
|
ZED
Superseded by part number: 87552612
|
| 23. |
322358
|
[4] |
BELLEVILLE WASHER,M8 Bolt Size x 18mm OD x 1.4mm Thk
|
NH
|
| 24. |
86000441
|
[6] |
NUT,M16 x 2.0, Cl 8
|
NH
|
| 25. |
320246
|
[2] |
BOLT,Hex, M16 x 2 x 70mm, Cl 8.8, Full Thd
|
NH
|
| 26. |
100020
|
[14] |
NUT,M16 x 2.0, Cl 8
|
NH
|
| 27. |
140048
|
[12] |
BELLEVILLE WASHER,M16 Bolt Size x 32mm OD x 2.8mm Thk
|
NH
|
| 28. |
86595832
|
[6] |
CARRIAGE BOLT,Sht Sq Nk, M16 x 40mm, Cl 8.8, Full Thd
|
NH
|
| 29. |
120090
|
[2] |
BOLT,Hex, M16 x 50mm, Cl 8.8
|
NH
|
| 30. |
9706687
|
[4] |
BOLT,M12 x 1.75 x 30mm, Cl 8.8
|
NH
|
| 31. |
84429978
|
[1] |
SUPPORT
|
ZED
|
| 32. |
86511315
|
[4] |
WASHER,8.4mm ID x 16mm OD x 1.8mm Thk
|
NH
Superseded by part number: 86624184
|
| 33. |
80292267
|
[1] |
BAND
|
ZED
L= 2.4 M
|
| 34. |
84449335
|
[4] |
CABLE TIE,346mm L
|
ZED
|
