神钢零件查询(K935) - EXCAVATOR SUPPLEMENT ASN LU00154 (1/76-12/03) (09-005) - LABEL, NAME PLATE(P/N 24100J7121F1,F4) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
935 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24100J7121F1 | [1] | LABEL, NAME-PLATE, Start Serial: LU.0124 | LABEL, NAME-PLATE, Start Serial: LU.0124 |
| . . | 24100J7121F4 | [1] | LABEL, NAME-PLATE | |
| 1. | 2432J690 | [2] | LABEL | KOB |
| 2. | 2432T1530 | [1] | IDENTITY PLATE | KOBWAPPEN |
| 3. | 2432N568 | [1] | INSTALLER JIG | KOBCAUTION Superseded by part number: 2432N1751 |
| 5. | 4020Z64 | [2] | RIVET | KOBOD 5.0 x 6.0mm Long Superseded by part number: 2420P623D7 |
| 6. | 2432T885 | [2] | PLATE | PLATE |
| 7. | 2432T892 | [1] | LABEL | KOB |
| 8. | 2432T1548 | [1] | PLATE, CAUTION | |
| 9. | 2432T1017 | [1] | LABEL | LABEL |
| 11. | 2432T959 | [1] | LABEL | KOB |
| 12. | 2432X269 | [1] | LABEL | KOB |
| 13. | 2432X297 | [1] | LABEL | KOB |
| 14. | 2432X296 | [1] | LABEL | KOB |
| 15. | 2432J1617 | [1] | NAME-PLATE | NAME-PLATE |
| 16. | 2432J1616 | [1] | NAME-PLATE | NAME-PLATE |
| 17. | 2432J1105 | [2] | LABEL | LABEL |
| 18. | 2432J1107 | [2] | LABEL | LABEL |
| 19. | 2432J1106 | [2] | LABEL | LABEL |
| 20. | 2432J1108 | [2] | LABEL | LABEL |
| 21. | 2432N1249D7 | [1] | LABEL | KOB |
| 22. | 2432J1095 | [1] | LABEL | KOB |
| 23. | 2432P1161 | [1] | LABEL | KOB |
| 24. | 2432J1112 | [1] | LABEL | LABEL |
| 25. | 2432J1142 | [2] | LABEL | LABEL |
| 26. | 2432P1183 | [1] | LABEL | LABEL |
| 27. | 24105P1059 | [1] | DIAGRAM, PAINTING | |
| 30. | 2432J1175 | [1] | LABEL, Start Serial: LU.0124 | |
| 31. | 2432J1690 | [1] | LABEL | |
| 33. | 2427232900 | [14] | SHEET | |
