凯斯零件查询(LBX332P) - BIG RECTANGULAR BALER ''PACKER CUTTER'' (3/03-12/08) (18.84070330[02]) - DIA : ROLLER BALE CHUTE Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
818 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| . . |
84070330
|
[1] |
DIA KIT, HARVESTER
|
ATT
|
| 1. |
84067162
|
[1] |
|
|
| 2. |
431941
|
[4] |
SUPPORT
|
DUB
|
| 3. |
430357
|
[8] |
CLAMP
|
DUB
|
| 4. |
43118
|
[2] |
BOLT,Hex, M6 x 1.0 x 40mm, Cl 8.8
|
NH
Superseded by part number: 120102
|
| 5. |
9850685
|
[1] |
BOLT,Hex, M6 - 1 x 90mm, Cl 8.8
|
NH
Superseded by part number: 190003800038
|
| 6. |
368582
|
[5] |
STRAP
|
GI
Superseded by part number: 263117
|
| 7. |
418284
|
[2] |
90 ELBOW
|
ZED
|
| 8. |
84078809
|
[2] |
FLEXIBLE HOSE
|
ZED
|
| 9. |
84071785
|
[1] |
HYD TUBE
|
ZED
|
| 9. |
84071787
|
[1] |
HYD TUBE
|
ZED
|
| 9. |
84449880
|
[1] |
HYD TUBE,479.6, 161.5 mm L
|
ZED
|
| 9. |
84449885
|
[1] |
HYD TUBE,465.6, 152.6 mm L
|
ZED
|
| 9. |
84432928
|
[1] |
HYD TUBE,10 mm OD
|
ZED
|
| 9. |
84432930
|
[1] |
HYD TUBE,10 mm OD
|
ZED
|
