纽荷兰零件查询(E70SR) - MIDI CRAWLER EXCAVATOR ASN YT04-07175 (01-001) - FRAME ASSY, UPP New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
870 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| A1. | YT52F00029P1 | [1] | FRAME, UPP | |
| . . | YT52F00031F3 | [1] | FRAME GROUP, UPP | |
| B1. | 2414Z220C2 | [1] | COVER | KOBDUST |
| B2. | YT52F01056P1 | [1] | PLATE | KOB |
| B3. | YT52F01001P1 | [1] | FOAM INSULATION | KOB |
| B4. | ZS18C08025 | [4] | SCREW,Hex, M8 x 25mm | KOBCAP |
| B5. | ZS13C16090 | [20] | CAPSCREW | KOBSCREW CAP |
| B6. | 2420T3453D2 | [3] | CAPSCREW | KOBSCREW CAP |
| B7. | YT52F01055P1 | [4] | SEAL | KOB |
| B8. | ZC46X16011 | [1] | CLIP | KOB |
| B9. | ZN18C10008 | [1] | NUT | KOBM10x1.50mm |
| B10. | ZW26X10000 | [1] | LOCK WASHER | KOBID 10 x OD 18 x Th 2.5mm |
| B11. | 2420R766D4 | [1] | GROMMET | KOB |
| B12. | YR52F01080D3 | [1] | RUBBER | KOB Superseded by part number: YY52F01567D5 |
| B13. | YR52F01080DB | [1] | RUBBER | KOB Superseded by part number: YY52F01567D5 |
| B14. | YR52F01080DC | [1] | RUBBER | KOB Superseded by part number: YY52F01567D5 |
| B15. | YJ21C01143D7 | [1] | RUBBER | KOB |
| B20. | YT52F01124P1 | [1] | INSULATING PANEL | KOB |
| B21. | YT52F01125P1 | [1] | INSULATING PANEL | KOB |
| B22. | YT52F01126P1 | [1] | INSULATING PANEL | KOB |
