神钢零件查询(K935) - EXCAVATOR SUPPLEMENT ASN LU00154 (1/76-12/03) (09-008) - LABEL, NAME-PLATE P/N 24100J5866F1 Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
359 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24100J5866F1 | [1] | LABEL. NAME-PLATE | |
| 1. | 2432J690 | [1] | LABEL | KOB |
| 2. | 2432T1530 | [1] | IDENTITY PLATE | KOBWAPPEN |
| 3. | 2432N568 | [1] | INSTALLER JIG | KOBCAUTION Superseded by part number: 2432N1751 |
| 4. | 2432T885 | [2] | PLATE | PLATE |
| 3. | 2432T1017 | [1] | LABEL | LABEL |
| 6. | 2432T892 | [1] | LABEL | KOB |
| 7. | 4020Z64 | [2] | RIVET | KOBOD 5.0 x 6.0mm Long Superseded by part number: 2420P623D7 |
| 8. | 2432T1548 | [1] | PLATE, CAUTION | |
| 9. | 2432T959 | [1] | LABEL | KOB |
| 10. | 2432J880 | [1] | NAME-PLATE | |
| 11. | 2432N988 | [2] | NAME-PLATE | |
| 12. | 2432N987 | [2] | NAME-PLATE | |
| 13. | 2432J881 | [2] | NAME-PLATE | |
| 14. | 2432J1175 | [1] | LABEL | |
