纽荷兰零件查询(E70SR) - MIDI CRAWLER EXCAVATOR ASN YT04-07175 (01-007) - RADIATOR ASSY New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
418 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YT05P00009F5 | [1] | RADIATOR | KOBASSY |
| 1. | NSS | [1] | NOT SERVICED SEPARATELY | CONCORE, RADIATOR |
| 2. | YT05P00009S002 | [1] | RADIATOR CAP | KOB |
| 3. | 2452U183S5 | [1] | PLUG | KOB |
| 4. | 2452U287S17 | [1] | HOSE | KOB |
| 10. | YW05P00009S010 | [8] | BOLT | KOBSEMS |
| 11. | YT05P00009S011 | [1] | OIL COOLER | KOB |
| 12. | YT05P00009S012 | [2] | INSULATION | |
| 13. | YT05P00009S013 | [1] | COVER | KOB |
| 14. | YW05P00009S003 | [4] | BOLT | KOBSEMS |
| 15. | YT05P00009S015 | [2] | NET | KOBCATCH, INSECT Superseded by part number: YT05P00009S023 |
| 16. | 2452U202S5 | [2] | BOLT | KOBWING |
| 17. | 2452U412S20 | [2] | WASHER | KOB |
| 20. | YT05P00009S020 | [1] | SHROUD | |
| 21. | YT05P00009S021 | [1] | BRACKET | KOB |
| 22. | YT05P00009S022 | [1] | BRACKET | KOB |
| . . | YT05P00009R100 | [1] | SERVICE KIT | KOBCONSISTS OF REF. 1, 2, 3, 4 |
