纽荷兰零件查询(E70SR) - MIDI CRAWLER EXCAVATOR ASN YT04-07175 (01-008) - CLEANER ASSY, AIR New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
682 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YT11P00006F1 | [1] | CLEANER ASSY, AIR | |
| 1. | YT11P01010P1 | [1] | HOSE | KOB |
| 2. | YT11P01014P1 | [1] | HOSE | KOB |
| 4. | YT11P01012P1 | [1] | BRACKET | KOB |
| 5. | YT11P00002F2 | [1] | FILTER ASSY | KOBASSY, AIR |
| 5-1. | YT11P00002S001 | [1] | BODY ASSY | |
| 5-2. | LE11P00002S002 | [1] | ELEMENT | KOBFILTER Superseded by part number: 87682994 |
| 5-3. | YT11P00002S003 | [1] | COVER ASSY | KOB |
| 5-4. | YT11P00002S004 | [1] | VALVE | KOBASSY |
| 5-5. | YR11P00008S005 | [1] | INDICATOR | KOB Superseded by part number: LV11P01017F1 |
| 5-6. | YT11P00002S006 | [1] | O-RING | KOB |
| 5-8. | YT11P00002S008 | [1] | RING | KOB |
| 7. | ZC16X06100 | [4] | CLIP | KOB |
| 8. | ZC16X07000 | [2] | CLIP | KOB |
| 9. | ZS18C08016 | [2] | SCREW,Hex, M8 x 16mm | KOBCAP |
| 10. | ZW16X08000 | [4] | WASHER | KOB |
| 14. | ZS18C08020 | [2] | SCREW,Hex, M8 x 20mm | KOB |
| 15. | YT11P01016P1 | [1] | RIGID TUBE | KOB |
| 16. | 2420T2948D5 | [1] | U-BOLT | KOBM08x1.25x ID 45 x 80.5mm Long |
| 17. | YR11P01021P1 | [1] | SPACER | KOB |
| 18. | YR11P01020P1 | [1] | FLEXIBLE HOSE | KOB |
| 19. | ZN18C08007 | [4] | NUT | KOBM08x1.25mm |
| 21. | ZC16X05000 | [2] | CLIP | KOB |
| 22. | LF11P01001P1 | [1] | LARGE HOSE | KOBHOSE,LARGE |
