神钢零件查询(K935) - EXCAVATOR SUPPLEMENT ASN LU00154 (1/76-12/03) (09-012) - LABEL, NAME PLATE P/N 24100J5438F1, F2 Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
439 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24100J5438F1 | [1] | LABEL, NAME-PLATE | |
| . . | 24100J5438F2 | [1] | LABEL, NAME-PLATE | |
| 1. | 2432J681 | [2] | NAME-PLATE | NAME-PLATE |
| 2. | 2432J1120 | [2] | NAME-PLATE | |
| 3. | 2432X269 | [1] | LABEL | KOB |
| 4. | 2432X270 | [1] | NAME-PLATE | |
| 5. | 2432X271 | [1] | NAME-PLATE | NAME-PLATE |
| 6. | 2432J1103 | [1] | NAME-PLATE | |
| 7. | 2432J1104 | [1] | NAME-PLATE | |
| 8. | 2432J1105 | [2] | LABEL | LABEL |
| 9. | 2432J1107 | [2] | LABEL | LABEL |
| 10. | 2432J1106 | [2] | LABEL | LABEL |
| 11. | 2432J1108 | [2] | LABEL | LABEL |
| 12. | 2432N1249D7 | [1] | LABEL | KOB |
| 13. | 2432J1095 | [1] | LABEL | KOB |
| 14. | 2432P1161 | [1] | LABEL | KOB |
| 15. | 2432J1112 | [1] | LABEL | LABEL |
| 16. | 2432T1142 | [2] | LABEL | KOB |
| 17. | 2432P1183 | [1] | LABEL | LABEL |
| 19. | 2432J1140 | [1] | LABEL | |
| 20. | 2432N970 | [1] | PLATE, INSTRUCTION | |
| 21. | 2432T1530 | [1] | IDENTITY PLATE | KOB |
| 22. | 4020Z64 | [2] | RIVET | KOBOD 5.0 x 6.0mm Long Superseded by part number: 2420P623D7 |
| 23. | 2432N563 | [1] | LABEL | |
| 24. | 2432T979 | [1] | LABEL | |
| 25. | 2432T888 | [1] | PLATE, CAUTION | PLATE, CAUTION |
| 26. | 2432T1753 | [1] | LABEL | KOBDecal, Kobelco Operation Superseded by part number: YN20T01407P1 |
| 27. | 2432Z287 | [1] | LABEL | KOB Superseded by part number: YN20T01408P1 |
| 28. | 2432T1754 | [1] | LABEL | LABEL |
| 29. | 2432T884 | [2] | LABEL | KOB |
| 30. | 2432J1695 | [1] | LABEL | |
| 31. | 2427Z329D2 | [14] | SHEET | KOBAnti-Slip (400x150mm) |
