纽荷兰零件查询(E70SR) - MIDI CRAWLER EXCAVATOR ASN YT04-07175 (01-013) - FUEL LINES New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
859 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YT21P00002F4 | [1] | FUEL LINES | |
| 5. | 2444R2492D360 | [1] | HOSE | KOB |
| 6. | 2444R2492D330 | [1] | HOSE | KOB |
| 7. | 2444R2492D025 | [1] | HOSE | KOB |
| 9. | 2418Z1333D8 | [1] | PROTECTIVE SLEEVE,19.5mm ID x 23.8mm OD x 1100mm Length | KOB |
| 10. | PY01P01008D2 | [1] | TUBE | KOB |
| 11. | PY01P01008D4 | [2] | RIGID TUBE | KOB |
| 12. | PY01P01043D3 | [8] | CABLE TIE,188mm L | KOBWire Ties -- 188mm Long |
| 13. | ZC16X01800 | [6] | CLIP | KOB |
| 14. | YN21P01003P1 | [1] | GROMMET | KOB |
| 29. | PY01P01043D5 | [3] | CABLE TIE,301mm L | KOB |
| 34. | PY01P01043D8 | [2] | CABLE TIE,102mm L | KOB |
| 38. | YM02P01039F1 | [1] | SEPARATOR | KOBASSY, WATER, SEE FIG. 01-014 |
| 39. | ZM22C08030 | [2] | BOLT | KOBSEMS |
| 40. | HX11Y06028DX | [1] | HOSE,10mm ID x 280mm L | KOB |
| 41. | ZC16X01200 | [1] | CLIP,8mm - 15mm | KOBClamp, Hose -- Min 08 x Max 15mm |
