凯斯零件查询(LBX332P) - BIG RECTANGULAR BALER ''PACKER CUTTER'' (3/03-12/08) (18.87390997[01]) - SERVICE KIT : ACCELERATED STUFFER Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
549 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| . . |
87390997
|
[1] |
SERVICE KIT
|
ZED
Superseded by part number: 87390998, 87524847, 87391000, 87390996, 140045, 87390995, 100016, 87531836, 320772
|
| 1. |
87390996
|
[1] |
PLATE
|
ZED
|
| 2. |
87390995
|
[1] |
PLATE
|
ZED
|
| 3. |
87391000
|
[1] |
RETAINER
|
ZED
|
| 4. |
87531836
|
[1] |
EXTENSION
|
ZED
|
| 5. |
320772
|
[1] |
HEX SOC SCREW,CSS, M10 x 30mm, Cl 8.8
|
ZED
|
| 6. |
140045
|
[1] |
BELLEVILLE WASHER,M10 Bolt Size x 22mm OD x 1.6mm Thk
|
NH
|
| 7. |
100016
|
[1] |
NUT,M10 x 1.5, Cl 8
|
NH
|
| . . |
87390998
|
[1] |
CAM
|
ZED
Superseded by part number: 85015890
|
| . . |
87524847
|
[1] |
DRILL
|
ZED
|
