凯斯零件查询(LBX332P) - BIG RECTANGULAR BALER ''PACKER CUTTER'' (3/03-12/08) (18.87631514[01]) - DIA : WIDTH SIGNAL PLATES KIT Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
1000 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| . . |
87631514
|
[1] |
DIA KIT, HARVESTER
|
ATT
|
| 1. |
80322358
|
[16] |
LOCK WASHER
|
ZED
Superseded by part number: 322358
|
| 1. |
89706690
|
[8] |
NUT,M8, Cl 8
|
ZED
Superseded by part number: 43362
|
| 2. |
120100
|
[4] |
BOLT,M6 x 20mm, Cl 8.8
|
NH
|
| 2. |
86507486
|
[4] |
CARRIAGE BOLT,M8 x 1.25 x 20mm, Cl 8.8
|
NH
|
| 3. |
9706690
|
[4] |
NUT,M8 x 1.25, Cl 8
|
NH
Superseded by part number: 43362
|
| 3. |
9706755
|
[4] |
NUT,M6, Cl 8
|
NH
Superseded by part number: 86500688
|
| 4. |
80325911
|
[8] |
RIVET
|
ZED
Superseded by part number: 325911
|
| 5. |
84607381
|
[4] |
PLATE
|
ZED
|
| 6. |
84429146
|
[2] |
SUPPORT
|
ZED
|
| 7. |
87648374
|
[1] |
SUPPORT
|
ZED
RH
|
| 7. |
87648372
|
[1] |
SUPPORT
|
ZED
LH
|
