纽荷兰零件查询(E70SR) - MIDI CRAWLER EXCAVATOR ASN YT04-07175 (01-020) - VALVE INSTAL New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
129 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 0. | YT30V00010F4 | [1] | CONTROL VALVE | KOBASSY |
| 0-1. | YT30V00007F1 | [1] | CONTROL | KOBVALVE ASSY, (ADD-ON) |
| 0-1A. | YT30V00017F1 | [1] | VALVE | KOBASSY, CONTROL Superseded by part number: YT30V00007F1 |
| 0-1B. | ZS23C12065 | [4] | SCREW,Hex Socket Head, M12 x 65mm | KOBCAP |
| . . | YT64H00031F1 | [1] | VALVE INSTAL | |
| 1. | YT64H01058P1 | [1] | BRACKET | KOB |
| 2. | ZS18C12030 | [7] | SCREW,Hex, M12 x 30mm | KOBCAP |
| 3. | ZW16H12000 | [7] | WASHER | KOB |
