纽荷兰零件查询(E70SR) - MIDI CRAWLER EXCAVATOR ASN YT04-07175 (01-029[02]) - CONTROL LINES, REMOTE, P/N YT64H00038F3 New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
662 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YT64H00038F3 | [1] | CONTROL LINES, VALVE | |
| 1. | ZH32X06000 | [1] | 90 ELBOW,Male, 30° Fl, PF 3/8" x PF 3/8", O-Ring | KOBElbow, 90° -- (Incls. O-Ring ZD12P01400) Alternate O-Ring 237-6006 |
| 2. | ZH32X04000 | [6] | 90 ELBOW,Male, 30° Fl, PF 1/4" x PF 1/4", O-Ring | KOB |
| 3. | HH25R06006GE | [1] | ELEC CONNECTOR | KOB |
| 4. | ZH42X04000 | [1] | 45 ELBOW,Male, 30° Fl, PF 1/4" x PF 1/4", O-Ring | KOB |
| 5. | ZS18C10070 | [2] | SCREW,Hex, M10 x 70mm | KOBCAP |
| 6. | ZW16X10000 | [2] | WASHER | KOB |
| 7. | 2420R537D045 | [1] | HOSE,9.60mm ID x 450mm L | KOB Superseded by part number: HX21E06045DX |
| 8. | 2420R349D330 | [2] | HYDRAULIC HOSE,6.35 mm ID x 3300.00 mm | KOB Superseded by part number: HX21E04330DX |
| 9. | 2420R349D135 | [1] | HOSE,6.35mm ID x 1350mm L | KOB |
| 10. | 2420R349D200 | [1] | HOSE ASSY. | KOB |
| 11. | 2420R349D250 | [1] | HOSE,2500.00 mm | KOB |
| 12. | YT64H01029D6 | [1] | RUBBER | KOB |
| 14. | 2444R1119D320 | [1] | HOSE | KOB |
| 15. | ZX23M06260 | [1] | HOSE | KOB |
| 17. | YT64H01029D5 | [1] | RUBBER | KOB |
| 18. | YT64H01027D1 | [1] | RUBBER | KOB |
| 19. | YN64H01018P1 | [2] | GROMMET | KOB |
| 20. | PY01P01043D6 | [11] | CABLE TIE,4.80mm W x 383mm L | KOB |
| 22. | ZH42X06000 | [2] | 45 ELBOW,Male, 30° Fl, PF 3/8" x PF 3/8", O-Ring | KOB |
| 23. | YT64H01029D2 | [1] | RUBBER | KOB |
| 24. | PU13E01010D9 | [1] | TUBE | KOB |
| 25. | 2420Z2185 | [1] | GROMMET | KOB |
| 26. | 2420R349D370 | [1] | HOSE,3700.00 mm | KOB Superseded by part number: HX21E04370DX |
| 27. | ZH32X04006 | [1] | 90 ELBOW,Male, 30° Fl, PF 1/4" x PF 3/8", O-Ring | KOB |
| 28. | PU13E01010DP | [1] | TUBE | KOB |
| 29. | YT35V00017F1 | [1] | SOLENOID VALVE | KOBVALVE ASSY, SOLENOID |
| 31. | YT64H01027D5 | [1] | RUBBER SLEEVE | KOBRUBBER, Start Serial: YT04-08292 |
| 32. | YT64H01095P1 | [1] | RUBBER, Start Serial: YT04-08292 | |
