神钢零件查询(K935) - EXCAVATOR SUPPLEMENT ASN LU00154 (1/76-12/03) (03-006) - CONTROL ASSY Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
670 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24100J7747F1 | [1] | CONTROL ASSY | |
| 1. | 2436P231F1 | [2] | VALVE PRESSURE RELIE | KOB |
| 2. | 2420R349D100 | [1] | HOSE | KOB1000mm Long (39-3/8 in) Superseded by part number: HX21E04100DX |
| 3. | 2420R349D120 | [1] | HOSE,6.35mm ID x 1200mm L | KOB |
| 4. | 2420R349D140 | [1] | HOSE,6.35mm ID x 1400mm L | KOB1/4" PF |
| 5. | 2420R349D160 | [1] | HOSE,6.35mm ID x 1600mm L | KOB |
| 6. | 2420R349D400 | [2] | FLEXIBLE HOSE | KOB4000mm Long (157-31/64 in) |
| 7. | ZH32X04000 | [9] | 90 ELBOW,Male, 30 Degree Fl, PF 1/4" x PF 1/4", O-Ring | KOBElbow, 90° -- PF 1/4, (Incls. O-Ring 237-6004) |
| 8. | ZH22X04000 | [3] | HYD CONNECTOR,1/4" NPT x 1/4" NPT | KOB1/4"PFx36mm Long (Incls. O-Ring ZD12P01100) |
| 9. | ZG22E04000 | [1] | HYD CONNECTOR | KOB |
| 10. | ZG52U04000 | [1] | TEE | KOB |
| 11. | ZS16C08014 | [4] | CAPSCREW | |
| 12. | ZW26X08000 | [4] | LOCK WASHER | KOBLock -- ID 08 x OD 15 x Th 2.0mm Superseded by part number: 83990583 |
| 13. | 2416P8179 | [2] | BRACKET | |
| 14. | ZH22Z04000 | [4] | HYD CONNECTOR | KOB1/4"PTx1/4"PFx37mm Long |
| 15. | 2444R515D1 | [2] | COUPLER | |
| 16. | ZG22B08004 | [1] | BUSHING | KOBCONNECTOR |
