| . . | 24100X1788F1 | [1] | CONTROL ASSY | |
| 1. | 2436U811F1 | [2] | VALVE, PILOT, Serial Range: LU.0096--LU.107 | VALVE, PILOT, Serial Range: LU.0096--LU.107 |
| 1. | 2436U811F6 | [2] | VALVE, PILOT, Serial Range: LU.0108--LU.0127 | VALVE, PILOT, Serial Range: LU.0108--LU.0127 |
| 1. | 2436U811F9 | [1] | PILOT VALVE | KOB, Start Serial: LU.0128- |
| 2. | 2436U386F1 | [2] | VALVE, REMOCON, Serial Range: LU.0096--LU.0100 | VALVE, REMOCON, Serial Range: LU.0096--LU.0100 |
| 2. | 2436U1062F1 | [2] | VALVE, REMOCON, Start Serial: LU.0101- | VALVE, REMOCON, Start Serial: LU.0101- |
| 3. | 24100N890F2 | [1] | LEVER ASSY, CONTROL, SEE FIG. 03-012 | |
| 4. | 2436R236F1 | [1] | VALVE, RELIEF VALVE, RELIEF | VALVE, RELIEF VALVE, RELIEF |
| 5. | 2446R151F1 | [1] | ELEMENT | KOBFILTER, LINE Superseded by part number: 2446R183F1 |
| 5-1. | 2446R151S1 | [1] | HEAD | KOB |
| 5-2. | R36P0019 | [1] | HYDRAULIC OIL FILTER | KOB |
| 5-3. | 45Z91D84 | [1] | O-RING | KOBID 56.74 ± 0.25 OD 63.80mm |
| 5-4. | 2446R151S4 | [1] | RING | KOB |
| 5-5. | 2446R151S5 | [1] | CASE | KOB |
| 6. | 2446U175F1 | [2] | FILTER | KOB |
| 6-3. | 2446U175S3 | [1] | SPARE PART | HITCARTRIDGE Superseded by part number: 2446U215S5P |
| 7. | 2483Z33 | [2] | VALVE | VALVE |
| 8. | 2416P4545 | [2] | STAND, CONTROL, Serial Range: LU.0096--LU.107 | STAND, CONTROL, Serial Range: LU.0096--LU.107 |
| 8. | 2416P4545D2 | [2] | , Start Serial: LU.0108- | |
| 9. | 2414R230 | [2] | BOOT | KOB, Start Serial: LU.0108- |
| 10. | 2416P8328 | [1] | STAND, CONTROL | |
| 11. | 2416P5306 | [1] | STAND, CONTROL | |
| 12. | 2406T1027 | [2] | LEVER | KOB |
| 13. | 2406P2065D2 | [1] | LEVER | KOB, Serial Range: LU.0096--LU.0103 Superseded by part number: 2406P2065D5 |
| 13. | 2406P2065D5 | [1] | LEVER | KOB, Start Serial: LU.0104 |
| 14. | 2406P2065D1 | [1] | BALL, LEVER, Serial Range: LU.0096--LU.0103 | BALL, LEVER, Serial Range: LU.0096--LU.0103 |
| 14. | 2406P2065D4 | [1] | LEVER | KOB, Start Serial: LU.0104 |
| 15. | 2419T2964 | [1] | PIN | PIN |
| 16. | 2418N2357 | [1] | PLATE, FLOOR, Serial Range: LU.0096--LU.0100 | |
| 16. | 2418N2384 | [1] | PLATE, FLOOR, Start Serial: LU.0101- | |
| 17. | ZS12C16090 | [4] | CAPSCREW | |
| 18. | 2414T1054 | [8] | COVER | KOB |
| 19. | 2416Z253 | [8] | RUBBER SLEEVE | KOB |
| 20. | ZN32C16015 | [4] | NUT | KOBM16x2.0mm |
| 21. | 2416T9226D1 | [4] | SPACER | |
| 22. | R16T0152D2 | [8] | WASHER | KOBFlat -- ID 17 x OD 30 x Th 3.2mm |
| 23. | 2444T1104 | [1] | ELBOW, 90 | ELBOW, 90 |
| 24. | 2444T1793 | [2] | HYD CONNECTOR | KOB |
| 25. | 2444Z1695D3 | [4] | CONNECTOR | CONNECTOR |
| 26. | R44T0224D1 | [2] | TEE | KOB |
| 27. | 2420R384D17 | [1] | HOSE | KOB |
| 28. | 2420R384D25 | [1] | HOSE | KOB |
| 29. | ZC15X02600 | [8] | CLAMP | KOB |
| 30. | ZD12P01800 | [2] | O-RING | KOBID 17.8mm x OD 20.2mm |
| 31. | 2420R537D200 | [3] | HOSE,9.60mm ID x 2000mm L | KOB |
| 32. | 2420R537D060 | [1] | HOSE ASSY.,9.60mm ID x 600mm L | KOB |
| 33. | 2420R537D100 | [1] | HOSE,9.60mm ID x 1000mm L | KOB |
| 34. | 2420R537D150 | [1] | FLEXIBLE HOSE,9.60mm ID x 1500mm L | KOB3/8" PF, 1500mm Long (59-1/16 in), Serial Range: -- Superseded by part number: HX21E06150DX |
| 35. | 2420R537D280 | [1] | HOSE,9.60mm ID x 2800mm L | KOB |
| 36. | 2420R349D040 | [12] | HOSE,6.35mm ID x 400mm L | KOB1/4" PF, 400mm Long (15-3/4 in) |
| 37. | 2420R349D120 | [2] | HOSE,6.35mm ID x 1200mm L | KOB |
| 38. | 2420R349D350 | [2] | FLEXIBLE HOSE | KOB3500mm Long (137-51/64 in) Superseded by part number: HX21E04350DX |
| 39. | 2420R349D380 | [1] | FLEXIBLE HOSE | KOB3800mm Long (149-39/64 in) Superseded by part number: HX21E04380DX |
| 40. | 2420R349D430 | [5] | HOSE | KOB |
| 41. | 2420R349D500 | [1] | HOSE | HOSE |
