神钢零件查询(K935) - EXCAVATOR SUPPLEMENT ASN LU00154 (1/76-12/03) (03-009) - CONTROL ASSY, LOADING (FOR NORWAY WRIST CONTROL TYPE) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
824 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24100J7427F1 | [1] | CONTROL ASSY, LOADING (FOR NORWAY WREST CONTROL TYPE | |
| 1. | 24100N1431F1 | [1] | PEDAL ASSY | |
| 1-1. | 2436U441F1 | [2] | VALVE | KOB |
| 1-2. | 2416P4451 | [2] | BRACKET | |
| 1-3. | 2414P1652 | [2] | COVER | |
| 1-4. | ZS23C06025 | [6] | SCREW,Hex Socket Head, M6 x 25mm | KOBM06x1.0x25mm |
| 1-5. | ZS23C08014 | [12] | SCREW,Hex Socket Head, M8 x 14mm | KOBM08x1.25x14mm |
| 1-6. | ZW22K08000 | [20] | LOCK WASHER | KOBID 08 x OD 13 x Th 2.0mm |
| 1-7. | 2422N46B | [1] | DECK, FLOOR | |
| 2. | ZH22Z04000 | [6] | HYD CONNECTOR | KOB1/4"PTx1/4"PFx37mm Long |
| 3. | ZH21K08004 | [2] | HYD CONNECTOR | KOB |
| 4. | 2444T1186 | [1] | TEE | TEE |
| 5. | ZH52X04000 | [1] | TEE,30 Degree Fl, Male, PF 1/4" x 1/4" x 1/4", O-Ring | KOB1/4" PF (Incls. O-Ring 237-6004) |
| 6. | ZH51K08000 | [2] | TEE | KOB |
| 7. | 2420R349D060 | [1] | HOSE,6.35mm ID x 700mm L | KOB600mm Long (23-5/8 in) |
| 8. | 2420R349D050 | [2] | HOSE,500.00 mm | KOB500mm Long (19-11/16 in) |
| 9. | 2420R349D470 | [1] | HOSE 4700mm Long (185-1/32 in) | HOSE 4700mm Long (185-1/32 in) |
| 10. | 2420R349D510 | [1] | HOSE | HOSE |
| 11. | ZX15K08090 | [1] | FLEXIBLE HOSE | KOBTUBE, NYLON |
| 12. | ZX15K08050 | [2] | PLASTIC-RUBBER TUBE | KOB |
| 13. | 2427R585 | [1] | MAT, FLOOR | |
| 14. | 2427U288 | [1] | MAT, FLOOR | |
