凯斯零件查询(LBX332R) - BIG RECTANGULAR BALER ''ROTOR CUTTER'' (3/03-12/08) (03.02[01]) - MAIN GEARBOX Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
788 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
84074471
|
[1] |
SET OF RINGS
|
ZED
|
| 2. |
84000818
|
[1] |
ROLLER BEARING
|
ZED
Superseded by part number: 26800090
|
| 3. |
84074446
|
[1] |
GEAR
|
ZED
|
| 4. |
84074483
|
[1] |
BEVEL GEAR
|
ZED
KIT
|
| 5. |
84000813
|
[1] |
ROLLER BEARING
|
ZED
Superseded by part number: 24903750
|
| 6. |
84074480
|
[1] |
O-RING
|
ZED
|
| 7. |
80300389
|
[8] |
BOLT,M12 x 35mm
|
ZED
M12 x 35 Superseded by part number: 628-12035
|
| 8. |
80412123
|
[8] |
LOCK WASHER
|
ZED
12.4 MM Superseded by part number: 412123
|
| 9. |
84074441
|
[1] |
COVER
|
ZED
|
| 10. |
84074455
|
[1] |
GASKET
|
ZED
|
| 11. |
84074467
|
[1] |
SHIM KIT
|
ZED
|
| 12. |
84074459
|
[1] |
COVER
|
ZED
|
| 13. |
80080681
|
[6] |
LOCK WASHER
|
IMO
8 MM Superseded by part number: 83990583
|
| 14. |
80043127
|
[6] |
SCREW,M8 x 25mm
|
ZED
M8 x 25 Superseded by part number: 43127
|
| 15. |
84074442
|
[1] |
COVER
|
ZED
|
| 16. |
84074453
|
[1] |
GASKET,0.2mm Thk
|
ZED
|
| 17. |
80536079
|
[1] |
SEALING ELEMENT
|
ZED
Superseded by part number: 536079
|
| 18. |
84074460
|
[2] |
SCREW
|
ZED
M8 x 16
|
| 19. |
84074464
|
[1] |
RING NUT
|
ZED
M70
|
| 20. |
26800020
|
[1] |
TAPERED BEARING,70mm ID x 125mm OD x 26.25mm W
|
ZED
|
| 21. |
84074469
|
[1] |
SHIM KIT
|
ZED
|
| 22. |
9839403
|
[1] |
TAPERED BEARING,75mm ID x 160mm OD x 58mm W
|
ZED
|
| 23. |
84320570
|
[1] |
INDICATOR
|
ZED
|
| 24. |
80394630
|
[2] |
WASHER
|
ZED
13 MM Superseded by part number: 86625256
|
| 25. |
84074465
|
[8] |
WASHER
|
ZED
|
| 26. |
84021936
|
[8] |
HEX SOC SCREW,M12 x 1.75 x 30mm, Cl 10.9
|
ZED
M12 x 30 Superseded by part number: 86512142
|
