凯斯零件查询(LBX332R) - BIG RECTANGULAR BALER ''ROTOR CUTTER'' (3/03-12/08) (05.12[01]) - TANDEM AUTO-STEER AXLE WITH BRAKES, REAR AXLE Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
121 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
84807547
|
[1] |
REAR AXLE
|
ZED
Incl. all refs.
|
| 1. |
84807556
|
[1] |
REAR AXLE
|
ZED
Incl. all refs.
|
| 1. |
84807548
|
[1] |
REAR AXLE
|
ZED
Incl. all refs.
|
| 1. |
84807557
|
[1] |
REAR AXLE
|
ZED
Incl. all refs.
|
| 2. |
NSS
|
[1] |
NOT SOLD SEPARAT
|
CON
Shaft
|
| 4. |
84100593
|
[2] |
BUSHING
|
ZED
|
| 5. |
84100594
|
[2] |
WASHER
|
ZED
|
| 6. |
84100609
|
[2] |
BUSHING
|
ZED
|
| 7. |
9672396
|
[4] |
NUT
|
WIN
|
| 8. |
84100616
|
[1] |
SUPPORT
|
ZED
RH
|
| 8. |
84100617
|
[1] |
SUPPORT
|
ZED
LH
|
| 8. |
84100647
|
[1] |
SUPPORT
|
ZED
RH
|
| 8. |
84100648
|
[1] |
SUPPORT
|
ZED
LH
|
| 9. |
120104
|
[16] |
BOLT,Hex, M8 x 1.25 x 20mm, Cl 8.8
|
NH
|
| 10. |
84100602
|
[4] |
COVER
|
ZED
|
| 11. |
84100603
|
[4] |
SLEEVE
|
ZED
|
| 12. |
84100605
|
[2] |
SHAFT
|
ZED
|
| 13. |
84014235
|
[4] |
SLEEVE
|
ZED
|
| 14. |
84100574
|
[2] |
SHAFT
|
ZED
|
| 15. |
80300632
|
[2] |
RETAINER
|
ZED
Superseded by part number: 11068676
|
| 16. |
84100586
|
[1] |
SWIVEL CONNECTION
|
ZED
|
| 17. |
80395528
|
[2] |
SCREW
|
ZED
M20 x 100 Superseded by part number: 395528
|
| 18. |
84100589
|
[1] |
NUT
|
ZED
|
| 20. |
84429121
|
[2] |
LEVER
|
ZED
|
| 20. |
84807627
|
[1] |
LEVER
|
ZED
RH
|
| 20. |
84807628
|
[1] |
LEVER
|
ZED
LH
|
| 21. |
84814994
|
[2] |
WASHER,26mm ID x 50mm OD x 3mm Thk
|
ZED
|
| 22. |
80370002
|
[2] |
CIRCLIP
|
ZED
Superseded by part number: 370002
|
| 23. |
84014244
|
[4] |
PIN
|
ZED
|
| 24. |
84014241
|
[4] |
SPRING
|
ZED
|
| 25. |
84014242
|
[2] |
CYLINDER
|
ZED
D= 25 MM
|
| 26. |
80380422
|
[1] |
SCREW
|
ZED
M20 x 90 Superseded by part number: 380422
|
| 27. |
84100597
|
[2] |
SCREW
|
ZED
M22 x 120
|
| 28. |
84100595
|
[1] |
BUSHING
|
ZED
|
| 29. |
84100599
|
[2] |
NUT
|
ZED
M27
|
| 30. |
84100600
|
[2] |
NUT
|
ZED
M27
|
| 31. |
84100598
|
[2] |
LOCK NUT
|
ZED
|
| 32. |
100020
|
[2] |
NUT,M16 x 2.0, Cl 8
|
NH
|
| 33. |
84100606
|
[2] |
SCREW
|
ZED
|
| 34. |
84100607
|
[4] |
WASHER
|
ZED
|
| 35. |
84100608
|
[2] |
RING
|
ZED
|
| 36. |
150024
|
[4] |
LUBE NIPPLE,45 Degree, M8 x 1
|
NH
|
| 37. |
80374890
|
[2] |
SCREW
|
ZED
Superseded by part number: 374890
|
| 38. |
89706694
|
[2] |
NUT,M20, Cl 8
|
ZED
Superseded by part number: 9706694
|
| 39. |
84100591
|
[2] |
SILENTBLOC
|
ZED
|
| 40. |
84100588
|
[1] |
SWIVEL CONNECTION
|
ZED
|
| 41. |
84100592
|
[1] |
SHOCK ABSORBER
|
ZED
|
| 42. |
84100601
|
[2] |
SEAL KIT
|
ZED
|
| 43. |
84100590
|
[1] |
BAR
|
ZED
Superseded by part number: 84197109, 84197109, 84197118
|
| 44. |
84100596
|
[1] |
STEERING CYLINDER
|
ZED
|
| 45. |
84807811
|
[2] |
PLATE
|
ZED
|
| 45. |
84807813
|
[2] |
PLATE
|
ZED
|
| 46. |
80280264
|
[4] |
SCREW
|
ZED
M14 x 50 Superseded by part number: 280264
|
| 47. |
80140069
|
[4] |
WASHER
|
ZED
Superseded by part number: 140069
|
| 48. |
80412370
|
[4] |
LOCK NUT
|
ZED
M14 Superseded by part number: 412370
|
| 49. |
84100604
|
[2] |
RING
|
ZED
|
| 50. |
325290
|
[1] |
NUT,M30, Cl 8
|
ZED
|
