| . . | 24100J10841F3 | [1] | INSTAL, POWER-PLANT | |
| 2. | 2437U204F1 | [2] | PUMP ASSY SEE(C.P.M) | PUMP ASSY SEE(C.P.M) |
| 4. | ZW26X10000 | [66] | LOCK WASHER | KOBID 10 x OD 18 x Th 2.5mm |
| 5. | 2418P20862 | [2] | PIPE | PIPE |
| 6. | 2418P20864 | [2] | PIPE | PIPE |
| 7. | 2418P20863 | [2] | PIPE | PIPE |
| 8. | 2420T4994 | [2] | HOSE | KOB |
| 9. | ZC15X07000 | [4] | CLIP | KOB |
| 10. | 2418T19299 | [2] | PIPE | KOB |
| 12. | ZN18C16013 | [8] | NUT | KOBM16x2.0mm |
| 13. | ZS23C10030 | [24] | SCREW,Hex Socket Head, M10 x 30mm | KOBM10x1.50x30mm Superseded by part number: ZS28C10030 |
| 14. | ZW26K10000 | [44] | LOCK WASHER | KOBLock -- ID 10 x OD 15.7 x Th 2.5mm Superseded by part number: 12581679 |
| 15. | 2416P4546D5 | [4] | STAY | |
| 16. | ZS18C12030 | [28] | SCREW,Hex, M12 x 30mm | KOBM12x1.75x30mm |
| 17. | ZW26X12000 | [60] | LOCK WASHER | KOBID 12 x OD 21 x Th 3.0mm |
| 18. | ZN18C12010 | [8] | NUT | KOBM12x1.75mm |
| 19. | ZW16X12000 | [8] | WASHER | KOBID 12 x OD 24 x Th 2.3mm |
| 20. | ZW16X10000 | [30] | WASHER | KOBID 10 x OD 21 x Th 2.0mm |
| 21. | ZS18F10030 | [6] | BOLT,Hex, M10 x 30mm | KOBM10x1.25x30mm |
| 22. | 2418T5373C2 | [6] | WASHER | KOBID 11 x OD 30 x Th 3.20mm Superseded by part number: 2418T12346 |
| 23. | ZS18C12035 | [16] | SCREW,Hex, M12 x 35mm | KOBM12x1.75x35mm |
| 25. | 24105T452 | [2] | WIRING, ELEC | |
| 26. | 2451U331F2 | [2] | ENGINE ASSY | |
| 27. | 2418P7485D3 | [2] | FLANGE | KOB |
| 28. | 2418U153F2 | [2] | COUPLING | KOB |
| 28-1. | 2453U147S40 | [4] | ELEMENT | KOB Superseded by part number: 2453U147S40M |
| 28-2. | 2453U147S41 | [4] | INSERT | KOB |
| 28-3. | 2453U147S42 | [4] | BUSHING | KOB |
| 28-5. | 2418U153S5 | [4] | SCREW | KOB |
| 28-6. | ZP26D08016 | [8] | ROLL PIN | KOB |
| 28-7. | ZS73C20025 | [2] | SET OF SCREWS | KOB |
| 28-8. | 2418P7532 | [1] | COUPLING | KOB |
| 29. | ZS23C20065 | [8] | SCREW,Hex Socket Head, M20 x 65mm | KOBM20x2.5x65mm |
| 30. | ZW26X16000 | [8] | LOCK WASHER | KOBID 16 x OD 28 x Th 4.0mm |
| 31. | ZS18C16045 | [8] | SCREW,Hex, M16 x 45mm | KOBM16x2.0x45mm |
| 32. | R18T0001D1 | [2] | HOSE | KOB |
| 33. | 2444Z1697D1 | [2] | HOSE | KOB |
| 34. | 2432R181D10 | [16] | CLAMP | KOB |
| 35. | 2432R181D3 | [8] | CLAMP | CLAMP |
| 36. | R18P0168D16 | [2] | HOSE | KOBØ31.8x170mm Long |
| 37. | 2444Z3379 | [2] | HOSE | KOB |
| 38. | 2432R182D5 | [8] | CLAMP | |
| 39. | ZS23C12030 | [8] | SCREW,Hex Socket Head, M12 x 30mm | KOBM12x1.75x30mm |
| 40. | ZW26K12000 | [24] | LOCK WASHER | KOBID 12 x OD 17.8 x Th 2.5mm |
| 41. | ZD11G04000 | [4] | O-RING,39.40mm ID x 45.60mm OD x 3.10mm | KOBID 39.40 ± 0.37 x OD 45mm |
| 42. | ZD11G02500 | [2] | O-RING,24.40mm ID x 30.60mm OD x 3.10mm | KOB |
| 43. | ZD11G06000 | [4] | O-RING,59.40mm ID x 65.60mm OD x 3.10mm | KOBID 59.40 ± 0.61 x OD 65mm |
| 45. | ZS23C06025 | [8] | SCREW,Hex Socket Head, M6 x 25mm | KOBM06x1.0x25mm |
| 46. | 2418T19495 | [1] | PLATE | |
| 47. | ZW26K06000 | [8] | LOCK WASHER | KOBID 06 x OD 11 x Th 1.5mm |
| 48. | ZS18C10025 | [28] | SCREW,Hex, M10 x 25mm | KOBM10x1.50x25mm |
| 49. | ZE72X04000 | [6] | PLUG | KOB(PF 1/4) (Incls. O-Ring ZD12P01100) |
| 50. | ZN18C10008 | [12] | NUT | KOBM10x1.50mm |
| 51. | 2418T5022 | [2] | PIPE | |
| 52. | ZS18C08016 | [1] | SCREW,Hex, M8 x 16mm | KOBM08x1.25x16mm |
| 53. | ZN18C08007 | [1] | NUT | KOBM08x1.25mm |
| 54. | 2452U206F1 | [2] | RADIATOR ASSY, SEE FIG. 07-008 | |
| 55. | 2414N2352 | [2] | GUARD, FAN | |
| 56. | 2450U5D14 | [2] | INDICATOR | KOB |
| 57. | 2437U207F1 | [2] | PUMP, GEAR | PUMP, GEAR |
| 58. | ZS18C08025 | [8] | SCREW,Hex, M8 x 25mm | KOBM08x1.25x25mm |
| 59. | ZW26X08000 | [9] | LOCK WASHER | KOBLock -- ID 08 x OD 15 x Th 2.0mm Superseded by part number: 83990583 |
| 62. | 2444Z1922 | [1] | HOSE | KOB |
| 63. | 2444Z1923 | [1] | HOSE | KOB |
| 65. | ZG41B06000 | [2] | ELBOW | KOB |
| 66. | 2444Z1293D10 | [2] | LUBE NIPPLE | KOBNipple, Hose -- 3/8" PTx46mm Long |
| 67. | ZC15X01300 | [2] | CLIP | KOB |
| 68. | 2420Z795D2 | [2] | FLEXIBLE HOSE | KOB Superseded by part number: 77254532, HX11Y07100DX |
| 69. | ZC15X08000 | [4] | CLIP | KOB |
