神钢零件查询(K935) - EXCAVATOR SUPPLEMENT ASN LU00154 (1/76-12/03) (07-008) - RADIATOR Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
277 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 2452U206F1 | [1] | RADIATOR | |
| 1. | 2452U101S6 | [1] | COOLER ASSY. | KOB |
| 2. | 2452U160S2 | [24] | CAPSCREW | |
| 4. | 2452U206S4 | [1] | RADIATOR ASSY CORE | RADIATOR ASSY CORE |
| 5. | 2452U136S7 | [1] | TUBE, VINYL PIPE,OVER FLOR | TUBE, VINYL PIPE,OVER FLOR |
| 6. | 2452U136S8 | [2] | CLIP | |
| 7. | 2452U136S9 | [1] | PLUG | KOBCAP,PRESSURE |
| 8. | 2452U136S21 | [1] | COCK | KOB |
| 9. | 2452U136S22 | [1] | TUBE, NYLON PIPE,DRAIN | TUBE, NYLON PIPE,DRAIN |
| 11. | 2452U206S11 | [1] | SHROUD | |
