纽荷兰零件查询(E70SR) - MIDI CRAWLER EXCAVATOR ASN YT04-07175 (01-054[01]) - CONDITIONER INSTAL New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
822 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YT20M00012F1 | [1] | CONDITIONER INSTAL | |
| 2. | YT03M01004P1 | [1] | SUPPORT | KOB |
| 3. | YT03M01038P1 | [1] | SUPPORT | KOB |
| 4. | YT20M01082P1 | [1] | SUPPORT | KOB |
| 5. | YT20M01083P1 | [1] | SUPPORT | KOB |
| 6. | YT20M01080P1 | [1] | RUBBER | KOB |
| 7. | YT20M01048P2 | [1] | DUCT | KOB |
| 8. | YT20M01049P1 | [1] | DUCT | KOB, Serial Range: YT04-07175-YT04-07449 Superseded by part number: YT20M01049P2 |
| 8. | YT20M01049P2 | [1] | DUCT | KOB, Start Serial: YT04-07450 |
| 9. | YT20M01050P1 | [1] | DUCT | KOB, Serial Range: YT04-07175-YT04-07449 Superseded by part number: YT20M01050P2 |
| 9. | YT20M01050P2 | [1] | DUCT | KOBDUCT, Start Serial: YT04-07450 |
| 10. | YT20M01051P1 | [1] | DUCT | KOB |
| 11. | YT20M01052P2 | [1] | DUCT | KOB |
| 12. | YT20M01053P1 | [1] | DUCT | KOB |
| 13. | YT20M01054P1 | [1] | DUCT | KOB |
| 14. | YT20M01122P1 | [1] | RUBBER | KOB |
| 15. | YT20M01123P1 | [1] | WASHER | KOB |
| 16. | ZS32T35012 | [1] | SCREW | KOBTAPPING |
| 18. | YT20M01099P1 | [1] | FOAM INSULATION | KOB |
| 20. | ZM46C05012 | [4] | BOLT | KOBSEMS |
| 22. | ZM61C06012 | [4] | BOLT | KOBSEMS |
| 23. | ZM61C06016 | [1] | BOLT | KOBSEMS |
| 24. | ZM61C06020 | [1] | BOLT | KOBSEMS |
| 25. | ZM22C08020 | [16] | BOLT | KOBSEMS |
